UltraBasic Portable Meter Specifications

Model	UP-5	UP-10	UB-25
pH Range	0.00 - 14.00	0.00 - 14.00	0.00 - 14.00
pH Resolution	0.01	0.01	0.01
pH Accuracy	0.005	0.005	0.005
mV Range	-	-1800.0 to +1800.0	-1800.0 to +1800.0
mV Resolution	-	0.1	0.1
mV Accuracy	-	0.2 mV or 0.05%	0.2 mV or 0.05%
Temperature Range	0.0 - 100.0o C	0.0 - 100.0o C	0.0 - 100.0o C
Temperature Resolution	0.1o C	0.1o C	0.1o C
Temperature Accuracy	0.2o C	0.2o C	0.2o C
Ion Range	-	-	0.0001 - 99900
Ion Resolution	-	-	1, 2, or 3 sig. figures
Ion Accuracy	-	-	0.34%



Common Specifications
Dimensions (LxWxH):	6.5" x 4.0" x 1.3" (165 x 102 x 33mm)
Net Weight:	0.6 lbs. (0.27kg)
Environmental:	15o - 40 o C

UltraBasic Benchtop Meter Specifications

	UB-5	UB-10
pH Range	0.00 - 14.00	0.00 - 14.00
pH Resolution	0.01	0.01
pH Accuracy	0.005	0.005
mV Range	-	-1800.0 to +1800.0
mV Resolution	-	0.1
mV Accuracy	-	0.2 mV or 0.05%
Temperature Range	0.0 - 100.0o C	0.0 - 100.0o C
Temperature Resolution	0.1o C	0.1o C
Temperature Accuracy	0.2o C	0.2o C



Common Specifications
Dimensions (LxWxH):	9.0" x 4.8" x 3.1" (229 x 121 x 79mm)
Net Weight:	0.6 lbs. (0.27kg)
Environmental:	15o - 40 o C
Power Requirements:	115V 50/60Hz, Additional voltages are available.

Sartorius Talent TE Budget Balances

The Sartorius Talent Series. Your access to talented weighing technology

The performance specifications of the Sartorius Talent series of balances set new accents in the class of compact and affordable laboratory balances. Whether you need to weigh in laboratories, vocational training facilities, classrooms or in the field, with a Sartorius Talent series balance you’ll always have just the right equipment.

TE models are standard-equipped with the following performance features:

• High-contrast LCD
• Bidirectional RS-232C interface port
• 4 digital filter levels to adapt the balance to the conditions at the place of use
• Built-in application programs: weighing in percent, net-total formulation, averaging; Dynamic weighing, counting of small parts, mass conversion by toggling between two weight units
• Battery-operable (8 + AA 1.5 V non rechargeable or rechargeable batteries). Models: TE612, TE412, TE212, TE6101, TE4101, TE2101, TE601, TE12000, TE6100, TE4100



Model
Readability	Capacity	Pan Size	Calibration	Model
Standard models
0.001 g	310 g	Ø 100 mm	extern	TE313S
0.001 g	310 g	Ø 100 mm	extern	TE313S-DS
0.001 g	150 g	Ø 100 mm	extern	TE153S
0.001 g	150 g	Ø 100 mm	extern	TE153S-DS
0.01 g	3100 g	174x143 mm	extern	TE3102S
0.01 g	1500 g	174x143 mm	extern	TE1502S
0.01 g	610 g	Ø 116 mm	extern	TE612
0.01 g	410 g	Ø 116 mm	extern	TE412
0.01 g	210 g	Ø 116 mm	extern	TE212
0.1 g	6100 g	174x143 mm	extern	TE6101
0.1 g	4100 g	174x143 mm	extern	TE4101
0.1 g	2100 g	174x143 mm	extern	TE2101
0.1 g	610 g	174x143 mm	extern	TE601
1 g	12000 g	174x143 mm	extern	TE12000
1 g	6100 g	174x143 mm	extern	TE6100
1 g	4100 g	174x143 mm	extern	TE4100
Verified models with EC type approval
0.01 g	0.5 - 510 g	Ø 116 mm	intern	TE512-0CE



Accessories
Group	Description	Order-Nr.
Carrying case	Carrying case (not for models with readability 0.1 mg and TE …-DS)	YDB01TE
Data printer	Ink ribbon cartridge, for YDP03-OCE	6906918
Data printer	Paper rolls, for YDP03-OCE; 5 units, each with 50 m	6906937
Data printer	Data printer, suitable for use in legal metrology; with date, time, statistics and transaction counter functions	YDP03-0CE
Data printer	Data printer with transaction counter (no GLP-printout possible)	YDP04
Foot switch	Foot switch, for activating the print, tare or F key; function can be selected by menu code; incl. T-connector for series CP, ED, LA, LE and TE	YFS01
Hand switch	Hand switch, for activating the print, tare or F key; function can be selected by menu code; incl. T-connector	YHS02
Interface cable	RS-232C interface cable, for connecting the balance to a PC with a 25-pin COM port; length approx. 1.5 m	7357312
Interface cable	RS-232C interface cable, for connecting the balance to a PC with a 9-pin COM port; length approx. 1.5 m	7357314
Interface cable	RS-232/USB connecting cable (length: approx. 1.8 m); CD with software drivers for installation under Windows 98/ME/2000/XP	YCC01-USBM2
Ionizing blower	Ionizing blower (220V) for electrostatically charged samples	YIB01-0DR
Ionizing blower	Ionizing blower (110V) for electrostatically charged samples	YIB01-0UR
Protective cover	Protective cover for display unit TE214S, TE124S, TE64, TE313S-DS, TE153S-DS	6960TE01
Protective cover	Protective cover for TE313S, TE153S, TE612, TE412, TE212	6960TE02
Protective cover	Protective cover for TE3102S, TE1502S, TE601, TE6101, TE4101, TE2101, TE12000, TE6100, TE4100	6960TE03
Rechargeable battery pack	External rechargeable battery pack, including battery charger	YRB08Z
Remote display	Remote display LCD; height of digits; 13 mm; reflective	YRD02Z
Software	SartoConnect, data transfer software, for direct input of weighing data into an application program (e.g., such as Excel) with RS232C standard cable, length: 1 m	YSC01L
Software	SartoConnect, data transfer software, for direct input of weighing data into an application program (e.g., such as Excel) with RS232C standard cable, length: 15 m	YSC01L15
Software	SartoConnect, data transfer software, for direct input of weighing data into an application program (e.g., such as Excel) with RS232C standard cable, length: 5 m	YSC01L5
Standard Operating Procedure (SOP)	Standard Operating Procedure (SOP) in German	YSL01D
Standard Operating Procedure (SOP)	Standard Operating Procedure (SOP) in English	YSL01E
Stat pen	Stat pen, unit to neutralize static electricity on samples (100V to 230V, 50/60Hz)	YSTP01
T-connector	T-connector, for connecting two peripheral devices to the balance	YTC01
Weighing bowls	Weighing bowl: Made of chrome nickel steel; without pouring spout; 1,000 ml capacity for balances with a weighing capacity > 300 g	641211
Weighing bowls	Weighing bowl: Made of chrome nickel steel; without pouring spout; 500 ml capacity	641212

Test and calibration weight for all TE models: extensive range of weights, alternatively with DKD certificate are available on request.

Additional accessories available on request



Sartorius Safety Weighing Cabinets



Greater protection and reliability in weighing hazardous powdered compounds

For researchers and laboratory technicians, the risks involved with handling toxic and high-potency compounds are considerable. Weighing even the smallest sample quantities can expose them to potential hazards. Appropriate protective measures must be taken to protect the health of all laboratory staff when they weigh hazardous compounds in powdered form. The Sartorius SWC Safety Weighing Cabinet offers important advantages in design and construction over traditional laboratory hoods: The SWC creates a contained area around the laboratory balance which prevents any air or finely powdered particulates from escaping into the operating personnel's work area. At the same time, the constant inlet air velocity and the special cabinet construction both keep the air current practically turbulence-free, and, as a result, ensure consistent and repeatable weighing results.

The balance and weighing cabinet are perfectly matched to each other. With its SWC Safety Weighing Cabinet, Sartorius has succeeded in uniting two otherwise contradictory requirements: maximum personnel protection and reliable weighing results.

The Safety Weighing Cabinets are available in four different dimensions for special applications, such as using a second laboratory balance in the cabinet or for unusually high structures:

SWC900 W 890 + D 750 + H 510 mm

SWC1200 W 1230 + D 750 + H 510 mm

SWC900T W 890 + D 750 + H 770 mm

SWC1200T W 1230 + D 750 + H 770 mm

Each of the four basic models consists of: Safety Weighing Cabinet with a separate HEPA filter unit, data-logging alarm, lighting unit, waste disposal system (on one side), airflow smoke test kit and antistatic cleaning wipes. Sartorius SWC Safety Weighing Cabinets comply with the requirements of EN14175.

Model with filter unit	Model without filter unit	Dimensions in mm (width + depth + height)
SWC900	SWC900NF	890 x 750 x 510
SWC1200	SWC1200NF	1230 x 750 x 510
SWC900T	SWC900TNF	890 x 750 x 770
SWC1200T	SWC1200TNF	1230 x 750 x 770



Accessories
YWCF02	Carbon filter for solvent vapours
YWCF03	Box for carbon filters; fixes to the fan filter box
YWCG01	Disposal chute for waste; fits to side of cabinet
YWCG02	Disposable chute bags, qty. of 100
YWCG03	Silencer unit option; attaches to exhaust of fan
YWCG04	Airflow smoke test kit
YWCG07	Anti-static decontamination wipes
YWCG14	Stainless steel bench, 890-mm wide units
YWCG15	Stainless steel bench, 1230-mm wide units
YWCG16	Printer table for mounting on the Safety Weighing Cabinet
Suitable laboratory benches and other accessories for our Safety Weighing Cabinets are available on request.



Sartorius Pipette Calibration Balances

Sartorius GPC Pipette Calibration Balances

The balances in the GPC series are ideally suited for gravimetric testing of the volume of any pipette size. A choice of sampling containers with capacities of 6 ml and 21 ml, respectively, enables you to test pipettes with a volume of up to 1,000µl, depending on the balance model you use. If you need to test volumetric apparatus that have a relatively high capacity, an optional 50 ml sampling container with a special pipette draft shield is available for GPC65-CW and GPC225-CW models.

Because these balances do not require an additional standard draft shield, this eliminates the need for opening and closing draft shield doors and saves considerable time. The calibration workstation’s modular design can be optimally adapted to your lab staff’s ergonomic needs..

Because the balances are standard-equipped with an evaporation trap, the humidity inside the sample chamber is maintained at 60 – 90% . Therefore, this prevents loss of liquid from the sampling container.

With the optional YDB01WZA carrying case, you can pack up your GPC pipette calibration balance along with the other accessories. Ambient conditions allowing, you have everything you need to calibrate your pipettes directly at the place of use.

• Easy pipetting without an interfering external draft shield chamber
• Consistently fast readouts, as there is no external draft shield chamber and therefore no more waiting after you open or close it
• Flexible, ergonomic setup of your work area thanks to modular design
• Minimizes errors caused by loss of liquid as the evaporation trap helps maintain the liquid volume



General Specifications

Weighing pan size (standard)	Ø 36 mm
Capacity of the sampling containers	6 ml / 21 ml
Data interface	RS-232C bidirectional
Calibration/Adjustment	Built-in, motorized
Display	GPC26-CW / GPC225-CW: White LED backlit graphic;  GPC65-CW: LCD

Product Attributes

	GPC26-CW	GPC65-CW	GPC225-CW
Readability	0.001 mg	0.01 mg	0.01 mg
Weighing capacity with standard pan	20 g	60 g	220 g
Pipetting weighing range	0.001 mg – 8 g	0.01 mg – 35 g	0.01 mg – 195 g

Accessories

PICASO pipette calibration software  (PC with Windows 98/2000/NT/XP required)	YCP03-2
Draft shield cylinder + 50 ml cylindrical sampling chamber (stainless steel)	YDS01WZA
Connecting cable (RS232) - PC (9-pin)	7357314
Carrying case	YDB01WZA



Pinnacle Precision Balances P-4002 - P-8002D

Top loading balances without compromises. Three years long-term guarantee.    Model Readability Capacity Pan size Calibration   P-4002 0,01g 4.000g 178x178mm external PI-4002 0,01g 4.000g 178x178mm internal PI-4002A 0,01g 4.000g 178x178mm internal-stamp approved P-2002 0,01g 2.000g 178x178mm external PI-2002 0,01g 2.000g 178x178mm internal PI-2002A 0,01g 2.000g 178x178mm internal-stamp approved P-4002D 0,01/0,1g 400/4.000g 178x178mm external PI-4002D 0,01/0,1g 400/4.000g 178x178mm internal P-8001 0,1g 8.000g 178x178mm external P-6001 0,1g 6.000g 178x178mm external PI-6001 0,1g 6.000g 178x178mm internal PI-6001A 0,1g 6.000g 178x178mm internal-stamp approved P-8002D 0,01/0,1g 800/8.000g 178x178mm external   Features Calibration time - and temperature-dependent (PI-series) Calibration external with user-definable weight (P-series) Stamp Approved (PI-4002A, PI2002A and PI-6001A only) Three communication ports:RS232C, USB and LAN Software for data transfer to windows applications via USB GLP/GMP-compliant protocols User Menu in German, English, Spanish and French Hook for weighing below Power supply   Applications Counting Weighing in % Weighing in different weigh units Formulation Animal weighing Target weighing Control (+/-) weighing Statistic





Pinnacle Precision Balances P-602 - PI-402

Top loading balances without compromises. Three years long-term guarantee.    Model Readability Capacity Pan size Calibration   P-602 0,01g 600g ø 114mm external PI-602 0,01g 600g ø 114mm internal PI-602A 0,01g 600g ø 114mm internal - stamp approved P-402 0,01g 400g ø 114mm external PI-402 0,01g 400g ø 114mm internal     Features Calibration time - and temperature-dependent (PI-series) Calibration external with user-definable weight (P-series) Stamp Approved (PI-602A only) Three communication ports:RS232C, USB and LAN Software for data transfer to windows applications via USB GLP/GMP-compliant protocols User Menu in German, English, Spanish and French Hook for weighing below Power supply   Applications Counting Weighing in % Weighing in different weigh units Formulation Animal weighing Target weighing Control (+/-) weighing Statistic

Pinnacle Precision Balances P-403 - PI-603D

Top loading balances without compromises. Three years long-term guarantee.    Model Readability Capacity Pan size Calibration   P-403 1mg 400g ø 114mm external PI-403 1mg 400g ø 114mm internal PI-403A 1mg 400g ø 114mm internal - stamp approved P-203 1mg 200g ø 114mm external PI-203 1mg 200g ø 114mm internal PI-203A 1mg 200g ø 114mm internal - stamp approved P-603D 0,001/0,01g 100g/600g ø 114mm external PI-603D 0,001/0,01g 100g/600g ø 114mm internal   Features Calibration time - and temperature-dependent (PI-series) Calibration external with user-definable weight (P-series) Stamp Approved (Only PI-403A and PI-203A) Three communication ports:RS232C, USB and LAN Software for data transfer to windows applications via USB User Menu in German, English, Spanish and French GLP/GMP-compliant protocols Hook for weighing below Power supply     Applications Counting Weighing in % Weighing in different weigh units Formulation Animal weighing Target weighing Control (+/-) weighing Statistic   Pinnacle Analytical Balances P-114 - PI-314     Analytical balances without compromises. Three years long-term guarantee.    Model Readability Capacity Pan size Calibration   P-314 0,1mg 310g ø 80mm external PI-314 0,1mg 310g ø 80mm internal PI-314A 0,1mg 310g ø 80mm internal - stamp approved P-214 0,1mg 210g ø 80mm external PI-214 0,1mg 210g ø 80mm internal PI-214A 0,1mg 210g ø 80mm internal - stamp approved P-114 0,1mg 110g ø 80mm external PI-114 0,1mg 110g ø 80mm internal PI-114A 0,1mg 110g ø 80mm internal - stamp approved     Features Calibration time - and temperature-dependent (PI-series) Calibration external with user-definable weight (P-series) Stamp Approved (PI-...A series) Three communication ports:RS232C, USB and LAN Software for data transfer to windows applications via USB GLP/GMP-compliant protocols User Menu in German, English, Spanish and French Hook for weighing below Power supply   Applications Counting Weighing in % Weighing in different weigh units Formulation Animal weighing Target weighing Control (+/-) weighing Statistic



NEW ELECTRODES!
pH and pH/ATC from Denver Instrument

Electrodes F-I

A. pH/ATC Plastic-body Combination Electrode for routine pH measurements. pH range 0 to 14, Ag/AgCl reference with free-flow fiber junction, "3-in-1" electrode has built-in temperature, integral glass bulb guard, 12 mm diameter, 120 mm length, temperature range -5°C to 80°C.

• 3M KCl liquid-filled electrode. BNC and 2.5mm phone plug connectors. Standard electrode for Denver Basic Meter.
  Cat. No. 300728.1
• 3M KCl refillable electrode. Waterproof Twist-Lock connector for Denver Portable Meters.
  Cat. No. 300750.1
• Gelled sealed reference electrode. For field use and low-maintenance requirements. Waterproof Twist-Lock connector for Denver Portable Meters.
  Cat. No. 300751.1

B. High performance pH/ATC Glass-body Electrode for all pH measurements, including TRIS samples. Glass body, pH 0 to 14 low resistance break-resistent toughened glass, super-stable 3M KCl liquid-filled reference cartridge system with nonclogging Free-Flow platinum junction, built-in temperature, BNC and 2.5 mm phone plug connectors, temperature range -5°C to 100°C.

• For use with all Denver benchtop pH meters. Standard electrode for Denver Series 200 and BASIC-Bio meters.
  Cat. No. 300729.1

C. High Performance Sleeve-Junction pH Electrode for routine or difficult pH measurements, viscous or low ionic strength samples. Polymer body, pH 0 to 14 low resistance glass, liquid-filled 3M KCl reference, adjustable flow rate plastic sleeve junction provides control over flow rate, allowing more accurate measurements, BNC connector, temperature range -5°C to 100°C.

• For use with all Denver meters
  Cat. No. 300738.1

D. pH Glass-body Combination Electrode for all pH measurements, including TRIS samples. Glass body, pH 0 to 14 low resistance break-resistent glass, super-stable 3M KCl refillable reference cartridge system with nonclogging Free-Flow platinum junction, BNC connector, temperature range -5°C to 100°C.

• For use with all Denver pH meters
  Cat. No. 300731.1

E. Micro Glass-body Combination pH electrodes for pH measurements in narrow containers, test tubes and labware. pH 0 to 14 low resistance glass, 3M KCl refillable reference system with nonclogging platinum junction, BNC connector, body diameter 0.20" (5mm).

• For use with all Denver pH meters.
  Cat. No. 300736.1

NEW ELECTRODES!
pH and pH/ATC from Denver Instrument

F. Flat-Surface Combination pH Electrode for pH measurements of small volumes or surfaces such as meats, cheese, leather or agar. Glass-body gel-filled sealed reference, pH 2 to 13 low resistance glass, temp. range -5°C to 50°C, BNC connector.

• For use with all Denver pH meters
  Cat. No. 300737.1

G. Plastic-body Gel-filled pH Electrode for field or plant measurements, where low-maintenance is desired. Polymer body, pH 0 to 14 low resistance glass, gel-filled reference with fiber junction, built-in bulb protector, BNC connector, temperature range -5°C to 80°C.

• For use with all Denver pH meters
  Cat. No. 300735.1

H. Solid-State FET pH/ATC Electrode for food processing or tough environments where non-glass durability is important. Solid-state Field Effect Transistor (FET) non-glass sensing device, polymer-body combination electrode with Ag/AgCl gelled sealed reference and ceramic junction, pH range 0 to 14, body diameter 0.37" (9.5mm), temperature range 0°C to 60°C, built-in temperature sensor.

• Multi-pin round DIN connector for 200 Series meters
  Cat. No. 300758.1
• Multi-pin round DIN connector for Denver Basic meter
  Cat. No. 300486.1
• Waterproof Twist-Lock connector for Denver Portable meters
  Cat. No. 300759.1

I. Automatic Temperature Compensating Probe for temperature measurement and correction. Fast response stainless steel body, 0.2" (4.7mm) diameter , 4.7" (120mm) length.

• With 2.5mm phone plug connector for Denver benchtop meters
  Cat. No. 300733.1
• With Waterproof Twist-Lock connector for Denver Portable meters
  Cat. No. 300752.1

NEW! Electrode Models from Denver Instrument
pH and pH/ATC Electrodes For routine pH measurements. pH range 0 to 14, Ag/AgCl reference with free-flow fiber junction, "3-in-1" electrode has built-in temperature, 12 mm diameter, 120 mm length, temperature range -5°C to 80°C. Conductivity Cells Conductivity Cells for Benchtop and Portable Meters. Four-band platinum conductivity cells offer better linearity and improved accuracy, built-in temperature, plastic body, 12mm diameter, cell constants from 0.5 to 10 cm-1. Removable outer body for cleaning.		Combination Ion-Selective State-of-the-art, convenient combination ISE's (with built-in reference electrode) for Fluoride, Chloride, Silver, Sodium, Ammonia, Nitrate, Potassium, Calcium or Sulfide measurement. Durable epoxy-body, BNC connector, 12 mm diameter, 110 mm length.

NEW ELECTRODES! Conductivity Cells from Denver Instrument J. Conductivity Cells for Benchtop and Portable Meters Four-band platinum band conductivity cells offer better linearity and improved accuracy, built-in temperature, plastic body, 12mm diameter, cell constants from 0.5 to 10 cm-1. Removable outer body for cleaning. Conductivity/ATC cell, 0.5 cm-1. Twist-Lock connector for Denver Portable Meters. Cat. No. 300754.1 Conductivity/ATC cell, 1 cm-1. Multi-pin connector for Denver 200 Series meters. Cat. No. 301047.1 Conductivity/ATC cell, 1 cm-1. Twist-Lock connector for Denver Portable Meters. Cat. No. 300755.1 Conductivity/ATC cell, 10 cm-1. Multi-pin connector for Denver 200 Series meters. Cat. No. 301048.1 Conductivity/ATC cell, 10 cm-1. Twist-Lock connector for Denver Portable Meters. Cat. No. 300756.1 K. Conductivity Cells for Denver benchtop meters (Models 20 - 150) Two-band platinum band conductivity cell, plastic body, 12mm diameter, cell constants from 0.1 to 10 cm-1. Dual pin tip plug connector. Conductivity cell, 0.1 cm-1 cell constant Cat. No. 300747.1 Conductivity cell, 1 cm-1 cell constant Cat. No. 300748.1 Conductivity cell, 10 cm-1 cell constant Cat. No. 300749.1		L. Multi-Sense Conductivity/pH/ATC Cells for Denver meters Super combination electrode includes a two-band platinum conductivity cell, combination pH electrode with gelled reference and an ATC temperature sensor. Plastic body, standard 12mm diameter and 120mm length. Cell constant 1.0 cm-1. Conductivity/pH/ATC Cell, BNC and multi-pin connectors for Denver benchtop meters. Cat. No. 301058.1





NEW ELECTRODES!
Combination ION-Selective Electrodes from Denver Instrument
M. State-of-the-art, convenient, combination ISEs (with built-in reference electrodes) for Fluoride, Chloride and Silver or Sulfide measurement. Membranes are LaF3 single crystal membrane (F-), solid-state Ag2S/AgCl (Cl-) or solid-state Ag2S (Ag+/S--), refillable references are single junction (F-) or double junction (Cl- and Ag+/S--) with high flow rate plastic sleeve junctions for accurate measurements, durable epoxy body, 12 mm diameter, 110 mm length, BNC connector.

Fluoride Combination ISE
Cat. No. 300739.1 Chloride Combination ISE
Cat. No. 300742.1 Silver/Sulfide Combination ISE
Cat. No. 300762.1

N. Nitrate, Potassium and Calcium Electrodes
Convenient combination ISEs use solvent-polymer PVC membrane technology. Built-in refillable reference electrodes are single junction (Ca++) or double junction (NO3- and K+) with high flow rate plastic sleeve junctions, durable epoxy body, 12 mm diameter, 120 mm length, BNC connector.

• Nitrate Combination ISE
  Cat. No. 300743.1
• Potassium Combination ISE
  Cat. No. 300744.1
• Calcium Combination ISE
  Cat. No. 300745.1

  O. Sodium Electrode
  Combination ISE uses a sodium selective glass membrane. Build-in liquid-filled reference electrode, glass body, 12 mm diameter, 110 mm length, BNC connector.
  Sodium Combination ISE
  Cat. No. 300741.1



P. Combination ORP electrode
Used to measure ORP (Oxidation Reduction Potential, or Redox Potential) in samples such as industrial waters. Convenient combination electrode includes Ag/AgCl reference with ceramic junction, large area platinum disc sensing element, BNC connector. ORP (Redox) Combination ISE
Cat. No. 300746.1

Q.Ammonia Electrode
Combination ISE uses a replaceable screw-on porous Teflon membrane module. Epoxy body, 12 mm diameter, BNC connector.

NEW ELECTRODES! Combination ION-Selective Electrodes from Denver Instrument M. Fluoride, Chloride and Silver/Sulfide Electrodes State-of-the-art, convenient, combination ISEs (with built-in reference electrodes) for Fluoride, Chloride and Silver or Sulfide measurement. Membranes are LaF3 single crystal membrane (F-), solid-state Ag2S/AgCl (Cl-) or solid-state Ag2S (Ag+/S--), refillable references are single junction (F-) or double junction (Cl- and Ag+/S--) with high flow rate plastic sleeve junctions for accurate measurements, durable epoxy body, 12 mm diameter, 110 mm length, BNC connector. Fluoride Combination ISE Cat. No. 300739.1 Chloride Combination ISE Cat. No. 300742.1 Silver/Sulfide Combination ISE Cat. No. 300762.1 N. Nitrate, Potassium and Calcium Electrodes Convenient combination ISEs use solvent-polymer PVC membrane technology. Built-in refillable reference electrodes are single junction (Ca++) or double junction (NO3- and K+) with high flow rate plastic sleeve junctions, durable epoxy body, 12 mm diameter, 120 mm length, BNC connector. Nitrate Combination ISE Cat. No. 300743.1 Potassium Combination ISE Cat. No. 300744.1 Calcium Combination ISE Cat. No. 300745.1 O. Sodium Electrode Combination ISE uses a sodium selective glass membrane. Build-in liquid-filled reference electrode, glass body, 12 mm diameter, 110 mm length, BNC connector. Sodium Combination ISE Cat. No. 300741.1		P. Combination ORP electrode Used to measure ORP (Oxidation Reduction Potential, or Redox Potential) in samples such as industrial waters. Convenient combination electrode includes Ag/AgCl reference with ceramic junction, large area platinum disc sensing element, BNC connector. ORP (Redox) Combination ISE Cat. No. 300746.1 Q.Ammonia Electrode Combination ISE uses a replaceable screw-on porous Teflon membrane module. Epoxy body, 12 mm diameter, BNC connector. Ammonia Combination ISE Cat. No. 300740.1
Specifications Denver Ion-Selective Electrodes Specifications Ion Measurement Range Slope (mV/decade) Temperature Range Response Time Filling Solution Fluoride 0.02 - Saturated -57 ± 2 0 to 80C 20 sec KCl Chloride 1.8 - 35000 -56 ± 2 0 to 80C 20 sec KNO3 Silver 0.01 - 108000 57 ± 2 0 to 80C 20 sec KNO3 Sulfide 0.003 - 32000 -27 ± 2 0 to 80C 20 sec KNO3 Ammonia 0.01 - 17000 56 ± 3 0 to 50C 60 sec NH4Cl Sodium 0.02 - Saturated 56 ± 2 0 to 80C 45 sec NH4Cl Nitrate 0.5 - 62000 57 ± 2 0 to 50C 30 sec (NH4)2SO4 Potassium 0.04 - 39000 56 ± 2 0 to 50C 30 sec NaCl Calcium 0.2 - 40000 27 ± 2 0 to 50C 30 sec KCl Denver Basic Bio pH Meter Exceptional ease of use Fast microprocessor operation Direct reading with either conventional glass or new FET* pH electrodes Three-point calibration (up to three buffers can be entered) Auto-recognition of 22 buffers Automatic electrode diagnostics Automatic temperature compensation Clear, accurate readings with large 1/2” high display numerals Stability indicator to aid in making measurements Stores two electrode calibrations; one for both glass and FET* electrodes Offers mV and relative mV modes Supplied with “3-in-1” plastic body, liquid-filled combination pH/ATC electrode For biotech and other researchers using TRIS buffers, choose the new BioBASIC pH Meter. BASIC pH Meter Specifications Modes pH mV Temperature Range -1.99 to +19.99 0 to ±1800.0 -5.0 to 105.0°C Resolution 0.01 0.1 0.1 Accuracy ±0.005 ±0.3 ±0.4 Connectors: BNC, 2.5mm phone, 9-pin mini-DIN, tip pin jack Automatic temperature compensation: -5 to +105°C; manual at 20°C or 25°C Operating Conditions: 15 to 40°C; 0 to 90% humidity (noncondensing) BASIC Meter Kit includes meter, electrode support arm and base combination pH/ATC electrode with ATC. International voltages are available. *FET: Solid-state Field Effect Transistor pH/ATC electrode   Two models to choose from: Model AP25 pH/mV/ion/temperature meter Model AP50 pH/mV/ion/conductivity/TDS/temperature meter   Easy-to-use operation with menus and prompts Research-grade accuracy in a portable meter Dedicated keys perform standardizing, change measurement mode, display electrode slope, display or print data Use up to five pH, ion, or conductivity standards Single or dual channel display Uses high-accuracy 4-electrode conductivity cell (AP50 model only) Programmable resolution to three decimal places Multiple electrode standardizations are stored and used Stores up to 250 data points with time, date, temperature, result, unit and sample number Clear, accurate readings with large 1/2” high display numerals Rugged, ergonomic design with rubber grip surfaces Waterproof to 1 meter (IP67 rated) and buoyant Supplied with “3-in-1” plastic body, liquid-filled combination pH/ATC electrode Supplied with soft-sided carrying case   Advanced Portable Meter Specifications   pH Range -2.000 to +20.000 pH Accuracy ±0.002 pH pH Resolution 0.001 pH mV Range -1,200.0 to +1,200.0 mV mV Accuracy ±0.1 mV mV Resolution 0.1 mV Conductivity Range ¹ 33ohm – 100Mohm† 300 mS/cm – .01 µS/cm† Conductivity Accuracy ¹ 0.1% Full Scale each sub-range Conductivity Resolution ¹ 1, 2, or 3 significant figures Temperature Range -5.0° to 105.0°C Temperature Accuracy ±0.4°C Temperature Resolution 0.1°C Standardization Up to 5 pH buffers, 5 ion and 5 conductivity standards Temperature Compensation Automatic, or Manual Electrode Slope Control Automatic or Manual Electrode Checking Automatic, Electrode error at <90% or >105% Operating Conditions 0 to 40°C, Waterproof to 1 meter Power Requirements 4 AA Alkaline Cells (50 hours Total Operating Time) Connectors Waterproof twist-lock, BNC, tip pin jack, power contacts, RS232C contacts



Denver pH 200 Series pH Meter



Quality for highest demands without compromises. The user is supported perfectly and all the requirements to GMP/GLP/ISO are totally fulfilled.



Modes for each Model
PH-215	pH/mV/temp
PH-220	pH/mV/temp/conductivity
PH-225	pH/mV/temp/ISE
PH-250	pH/mV/temp/conductivity/ISE



Modes	pH	mV	Temperature
Ranges	-2.000 to 20.000	±2.400	-5,0 to 105,0 °C
Resolution	0,001/0,01/0,1	0,1/1	0,1
Accuracy	±0,001 pH	±0,05 mV	±0,1 °C
Temp Compensation	Automatic and manual: -5 to 105 °C
Slope Control	Automatic, 90 to 105%; manual, 80 to 110%
Environment	15 - 40 °C, 0 - 90% relative humidity
Ion Mode (Models 250/225)
Range	1,00 x 10-9 to 9,99 x 109
Resolution	1, 2, 3 significant digits
Relative accuracy	±0,09 n%
Conductivity Mode (Models 250/220)
Conductivity Range	0 to 300.000 µs/cm (depending on cell constant)
Relative accuracy	0,5% reading
Salinity ranges	Autoranging, 0.01 to 70ppt NaCl equivalent salinity Autoranging, 0.01 to 42ppt NaCl practical salinity
Resistivity	30 Ohm•cm to 1, 10 oder 20 Megohm•cm (at cell constants of 10, 1, 0.5cm-1respectively). Autoranging units; readout in ohm?cm, kilohm?cm, or megohm?cm. Fixed units: kilohm?cm
Total dissolved solids	0,005 to 1,5 x 105 mg/L (at 0.5 solids factor, depending on cell constant)
Temp coefficient	Software configurable; off or on, 0 to 4%/°C



Meter kits includes: Meter, power supply, high performance glass-body pH/ATC electrode 300729-1, electrode arm and operation manual.



Features

Large , multifunctional, backlit display

Plain language menus

Soft Key Help Function

5 Calibration Points

Auto-buffer recognition of 27 buffers

Storage for up to 620 results

RS232 Data Interface

Complete GLP/GMP/ISO documentation

Specifications and Ordering Information

Mode	Ion	pH	mV
Ranges	1.00 x10-9 to 9.99 x 109	-2.000 to 20.000	±1800.0
Resolution	1, 2, 3 significant digits	0.001/0.01/0.1	0.1/1
Relative Accuracy	± 0.17n%	±0.002	±0.1
Temperature Measurement	-5.0 to 105°C; relative accuracy, ±0.3°C	Temperature Compensation	Manual Automatic, -5.0 to 105°C
Slope Control	Automatic 90 to 105%, Manual 80 to 110%
Environmental Conditions	15° to 40°C, 0 to 90% Relative Humidity
Conductivity Mode
Conductivity Ranges	Cell Constant
	10cm-1	1.0cm-1	0.5cm-1
Subrange 5 Subrange 4 Subrange 3 Subrange 2 Subrange 1	3x104 to 3x105 3x103 to 3x104 3x102 to 3x103 3x101 to 3x102 0 to 3x101	3x103 to 3x104 3x102 to 3x103 3x101 to 3x102 3x100 to 3x101 0 to 3x100	1x103 to 1x104 1x102 to 1x103 1x101 to 1x102 1x100 to 1x101 0 to 1x10-1
Relative Accuracy	0.5% of reading
Salinity Ranges	Autoranging, 0.01 to 70ppt NaCl equivalent salinity Autoranging, 0.01 to 42ppt practical salinity
Resistivity	30ohm•cm to 1, 10 or 20megohm•cm (at cell constants of 10, 1, 0.5cm-1 respectively). Autoranging units; readout in ohm•cm, kilohm•cm, or megohm•cm. Fixed units: kilohm•cm
Total Dissolved Solids	0.005 to 1.5x105 mg/L (at 0.5 solids factor, depending on cell constant)
Temp Coefficient	Software configurable; Off or On 0 to 4%/°C
Excitation Frequency	225 Hz
Power Requirements:	115V 50/60Hz (Additional voltages available)
Ordering Information
Meter with kit includes:	Meter, power supply, high performance glass-body pH/ATC "3-in-1" electrode, electrode arm and operation manual.
The Meter only includes:	Meter, power supply, electrode arm and operation manual.
Meter with Kit	Cat. No. 9454.X
Meter Only	Cat. No. 9459.X

Model 225 from Denver Instrument The perfect meter for ion-selective analyses, plus pH, mV and ºC! Three electrode inputs Simultaneous one, two or three channel measurements Direct and indirect ISE readouts Direct reading with glass or FET electrodes
Specifications and Ordering Information Modes Ion pH mV Temperature Range 1.00 x 10-9 to 9.99 x 109 -2.000 to 20.000 ±1800.0 -5.0 to +105.0°C Resolution significant digits 1, 2 or 3 0.1/0.01/0.001 1/0.1 0.1 Accuracy ± 0.17n% ±0.002 ± 0.1 ±0.3 Temperature Compensation Automatic or manual, from -5° to 105°C Slope Control Automatic, 90 to 105%, manual, 80 to 110% Environmental Conditions 15° to 40°C, 0 to 90% (noncondensing) Relative Humidity   Power Requirements 115V 50/60Hz (Additional voltages available)   Ordering Information Meter with kit includes Meter, power supply, high performance glass-body pH/ATC "3-in-1" electrode, electrode arm and operation manual. The Meter only includes Meter, power supply, electrode arm and operation manual. Meter with Kit Cat. No. 9452.X Meter Only Cat. No. 9457.X



Specifications and Ordering Information

Conductivity Range	0.01 to 3 x 105 µS/cm (depending on cell constant)
Resolution	1, 2 or 3 significant figures
Accuracy	± 0.5% of reading
Cell Constant Sub-Range Sub-Range Sub-Range Sub-Range Sub-Range	10cm-1 3 x 104 to 3 x 105 3 x 103 to 3 x 104 3 x 102 to 3 x 103 3 x 101 to 3 x 102 0 to 3 x 101	1.0 cm-1 3 x 103 to 3 x 104 3 x 102 to 3 x 103 3 x 101 to 3 x 102 3 x 100 to 3 x 101 0 to 3 x 100	0.5 cm-1 1 x 103 to 1 x 104 1 x 102 to 1 x 103 1 x 101 to 1 x 102 1 x 100 to 1 x 11 0 to 1 x 10-1
NaCl Equivalent Salinity	Autoranging, 0.01 to 70ppt
Practical Salinity	Autoranging, 0.01 to 42ppt
Resistivity	Autoranging, 30 ohm•cm to 20 Megohm•cm (depending on cell constant)
Temperature Correction	Off or On, 0 to 4%/°C
Excitation Frequency	225 Hz
Replatinizing Circuit	2.5V, open circuit; 7.5mA, short circuit
Modes	pH	mV	Temp
Range	-2.000 to 20.000	±1800.0	-5.0 to 105.0°C
Resolution	0.1/0.01/0.001	1/0.1	0.1°C
Accuracy	±0.002	±0.1	0.3°C
Automatic Temperature Compensation	Automatic or manual from -5 to 105°C.
Slope Control	Automatic 90 to 105% Manual, 80 to 110%
Environmental Conditions	15° to 40°C, 0-90% RH
Power Requirements:	115V 50/60Hz (Additional voltages available)
Ordering Information
Meter with kit includes:		Meter, power supply, high performance glass-bodypH/ATC "3-in-1" electrode, electrode arm and operation manual.
The Meter only includes:		Meter, power supply, electrode arm and operation manual.
Meter with Kit	Cat. No. 9451.X
Meter Only	Cat. No. 9456.X



Research-Grade Meters from Denver Instrument



  Model 250

A multimeter for electrochemical analysis!
pH, ion, mV, Cond, ºC!

Model 225

The perfect meter for ion-selective analyses, plus pH, mV and ºC!



Model 215

The Model 215 offers the most accurate pH measurements available.



Model 220

Research-grade pH and conductivity measurements from one meter

NEW METERS! Model 220 from Denver Instrument Research-grade pH and conductivity measurements from one meter Simultaneous pH and conductivity measurements, even in the same solution! Offers conductivity, NaCl salinity, practical salinity, resistivity and Total Dissolved Solids Improved conductivity measurements with 4-cell conductivity and multiple standards Three electrode inputs Replatinizing circuit for renewing your conductivity cells Fully compliant with the new USP 23 conductivity protocol Standardizes in all conductivity modes

Model 215 from Denver Instrument The Model 215 offers the most accurate pH measurements available. Reliable and affordable research-grade pH measurements. Accuracy to 0.002 pH units Automatic recognition of 22 different buffers Five custom user-entered buffers Single or dual channel measurements Automatic electrode checking Graphical display of electrode calibration curve Built-in context-sensitive help Dual pH electrode inputs
Specifications and Ordering Information Modes pH mV Temperature Range -2.000 to 20.000 ±1800.0 -5.0 to 105.0°C Resolution 0.001/0.01/0.1 0.1/1 0.1 Accuracy ±0.002 ±0.1 ± 0.3 Temperature Compensation Automatic & manual:-5 to 105°C Slope Control Automatic, 90 to 105% Manual, 80 to 110% Environmental Conditions 15 to 40°C, humidity from 0 to 90% (noncondensing) Power Requirements 115V 50/60Hz (Additional voltages available) Ordering Information   Meter with kit includes: Meter, power supply, high performance glass-body pH/ATC "3-in-1" electrode, electrode arm and operation manual. The Meter only includes: Meter, power supply, electrode arm and operation manual. Meter with Kit Cat. No. 9450.X Meter Only Cat. No. 9455.X



Sartorius Micro ME/SE Balances



Sartorius Micro. Premium Micro- and Ultra-microbalances ME5 and SE2. Maximum precision for minimum sample quantities.

Uncompromising weighing technology is the No. 1 priority. Incomparably fast response and display of weighing results and exceptional repeatability meet the very highest demands on accurate weighing. These results unconditionally measure up to the strictest requirements of both legal regulations and quality management systems.

• Astonishingly fast response times with only 10-second stabilization time needed
• Self-teaching, all-glass draft shield for ergonomic handling of the smallest sample quantities
• Complete functionality for use as measuring and test equipment, with fully automatic calibration and adjustment function, isoCAL; the SQmin function for displaying the minimum allowable sample quantity according to the USP; and S.U.R.E. display of the uncertainty of measurement to comply with stringent accuracy standards, such as DKD (German Calibration Service)
• 14 built-in application programs as standard features, such as EUREKA program for air buoyancy correction, Differential weighing program for up to 999 samples, Statistical evaluation. All balance-generated data can be logged via the standard RS-232C interface port
• Models ME5-F and SE2-F for weighing filters of up to 90 mm in diameter. The draft shield specifically constructed for this application is made completely of metal, thereby minimizing the interfering effects of static electricity



Model
Readability	Capacity	Pan Size	Calibration	Model
Standard models
0.0001 mg	2.1 g	Ø 20 mm	intern	SE2
0.0001 mg	2.1 g	Ø 50 oder/or 20 mm	intern	SE2-F
0.001 mg	5.1 g	Ø 30 mm	intern	ME5
0.001 mg	5.1 g	Ø 50 oder/or 30 mm	intern	ME5-F
Verified models with EC type approval
0.0001 mg	0.1 mg - 2.1 g	Ø 20 mm	intern	SE2-0CE
0.001 mg	0.1 mg - 5.1 g	Ø 30 mm	intern	ME5-0CE



Accessories
Group	Description	Order-Nr.
Antistatic weighing pan	Antistatic weighing pan for ME5	YWP01MC
Balance table / Wall console	Balance table, for precise, reliable weighing operations	YWT01
Balance table / Wall console	Balance table, cast stone with damping device	YWT03
Balance table / Wall console	Wall console	YWT04
Bar code scanner	Bar code scanner, for SE2, all LA and ME models (YCC01-0024M01 required)	YBR02FC
Bar code scanner	Cable for connecting the bar code scanner	YCC01-0024M01
Data interface	Data interface, PC-compatible (9-pin COM port) for all ME models incl. 5-pin connector for bar code scanner	YDO01ME
Data interface	Data interface, RS-485 (12-pin COM port, round) for all ME models incl. 5-pin connector for bar code scanner	YDO02ME
Data printer	Ink ribbon cartridge, for YDP03-OCE	6906918
Data printer	Paper rolls, for YDP03-OCE; 5 units, each with 50 m	6906937
Data printer	Data printer, suitable for use in legal metrology; with date, time, statistics and transaction counter functions	YDP03-0CE
Extension cable	Cable for connecting the weighing cell to a separate display and control unit (length:2.70 m), for all ME models and SE2	YCC01-MED27
Foot switch	Foot switch, incl.T-connector for all ME models and SE2	YPE01RC
Hand switch	Hand switch, for activating the print, tare or F key; function can be selected by menu code; incl. T-connector	YHS02
Interface cable	RS-232C interface cable, for connecting the balance to a PC with a 25-pin COM port; length approx. 1.5 m	7357312
Interface cable	RS-232C interface cable, for connecting the balance to a PC with a 9-pin COM port; length approx. 1.5 m	7357314
Interface cable	RS-232/USB connecting cable (length: approx. 1.8 m); CD with software drivers for installation under Windows 98/ME/2000/XP	YCC01-USBM2
Ionizing blower	Ionizing blower (220V) for electrostatically charged samples	YIB01-0DR
Ionizing blower	Ionizing blower (110V) for electrostatically charged samples	YIB01-0UR
Rechargeable battery pack	External rechargeable battery pack for balances with a weighing capacity up to ... - Series CP: 8.2 kg - Series LE: 10.2 kg - Series ED: all models - Series ME: all models - Series SE: all models	YRB05Z
Remote display	Remote display LCD; height of digits; 13 mm; reflective	YRD02Z
Software	SartoConnect, data transfer software, for direct input of weighing data into an application program (e.g., such as Excel) with RS232C standard cable, length: 1 m	YSC01L
Software	SartoConnect, data transfer software, for direct input of weighing data into an application program (e.g., such as Excel) with RS232C standard cable, length: 15 m	YSC01L15
Software	SartoConnect, data transfer software, for direct input of weighing data into an application program (e.g., such as Excel) with RS232C standard cable, length: 5 m	YSC01L5
Standard Operating Procedure (SOP)	Standard Operating Procedure (SOP) in German	YSL01D
Standard Operating Procedure (SOP)	Standard Operating Procedure (SOP) in English	YSL01E
Stat pen	Stat pen, unit to neutralize static electricity on samples (100V to 230V, 50/60Hz)	YSTP01
T-connector	T-connector, for connecting two peripheral devices to the balance	YTC01
Weight set	Weight set for determination of the air density, for ME5	YSS35-00

Sartorius ME Analytical Balances

Sartorius ME. Analytical balances with the highest credentials.

The Sartorius ME is highly proficient at performing the core tasks of analytical weighing with incomparable speed, stable accuracy and reliability.

• Stable and reproducible readouts with an accuracy of five decimal places in just eight seconds
• Three-part, motorized draft shield system; controlled by palm-activated keys or by custom programming
• Excellent repeatability and stable weight readouts
• Built-in software for all key weighing applications in the lab
• Provides complete support for use as a test and measuring instrument; with isoCAL feature for performing automatic calibration and adjustment, SQmin function for determining the allowable minimum sample weight according to the USP, and function for determining the uncertainty of measurement according to the German Calibration Service DKD
• Three-year warranty; optionally extendable up to five years



Model
Readability	Capacity	Pan Size	Calibration	Model
Standard models
0.01 mg	230 g	Ø 90 mm	intern	ME235S
0.01/0.02/0.05 mg	60 / 110 / 230 g	Ø 90 mm	intern	ME235P
0.01/0.02/0.05 mg	60/110/230 g	Ø 90 mm	intern	ME235P-SD
0.1 mg	610 g	Ø 90 mm	intern	ME614S
0.1 mg	410 g	Ø 90 mm	intern	ME414S
0.1 mg	250 g	Ø 90 mm	intern	ME254S
Verified models with EC type approval
0.01 mg	1 mg - 230 g	Ø 90 mm	intern	ME235S-0CE
0.01/0.02/0.05 mg	1 mg - 230 g	Ø 90 mm	intern	ME235P-0CE
0.1 mg	10 mg - 610 g	Ø 90 mm	intern	ME614S-0CE
0.1 mg	10 mg - 410 g	Ø 90 mm	intern	ME414S-0CE
0.1 mg	10 mg - 250 g	Ø 90 mm	intern	ME254S-0CE



Accessories
Group	Descripion	Order-Nr.
		YDK01-0D
Antistatic weighing pan	Antistatic weighing pan for all ME models (0.1 mg and 0.01 mg readability)	YWP01ME
Balance table / Wall console	Balance table, for precise, reliable weighing operations	YWT01
Balance table / Wall console	Balance table, cast stone with damping device	YWT03
Balance table / Wall console	Wall console	YWT04
Bar code scanner	Bar code scanner, for SE2, all LA and ME models (YCC01-0024M01 required)	YBR02FC
Bar code scanner	Cable for connecting the bar code scanner	YCC01-0024M01
Carrying case	Carrying case for all ME models (0.1 mg and 0.01 mg readability)	YDB01ME
Data interface	Data interface, PC-compatible (9-pin COM port) for all ME models incl. 5-pin connector for bar code scanner	YDO01ME
Data interface	Data interface, RS-485 (12-pin COM port, round) for all ME models incl. 5-pin connector for bar code scanner	YDO02ME
Data printer	Ink ribbon cartridge, for YDP03-OCE	6906918
Data printer	Paper rolls, for YDP03-OCE; 5 units, each with 50 m	6906937
Data printer	Data printer, suitable for use in legal metrology; with date, time, statistics and transaction counter functions	YDP03-0CE
Density determination kit	Density determination kit for - CP225D, CP324S, CP224S, CP124S - all ME models (0.1 mg and 0.01 mg readability) and LA models (0.1 mg readability) - LE225D	YDK01
Extension cable	Cable for connecting the weighing cell to a separate display and control unit (length:2.70 m), for all ME models and SE2	YCC01-MED27
Foot switch	Foot switch, incl.T-connector for all ME models and SE2	YPE01RC
Glass plate support	Glass plate support for conditioning samples inside the weighing chamber for all ME models (0.1 mg and 0.01 mg readability)	YGS01ME
Hand switch	Hand switch, for activating the print, tare or F key; function can be selected by menu code; incl. T-connector	YHS02
Interface cable	RS-232C interface cable, for connecting the balance to a PC with a 25-pin COM port; length approx. 1.5 m	7357312
Interface cable	RS-232C interface cable, for connecting the balance to a PC with a 9-pin COM port; length approx. 1.5 m	7357314
Interface cable	RS-232/USB connecting cable (length: approx. 1.8 m); CD with software drivers for installation under Windows 98/ME/2000/XP	YCC01-USBM2
Ionizing blower	Ionizing blower (220V) for electrostatically charged samples	YIB01-0DR
Ionizing blower	Ionizing blower (110V) for electrostatically charged samples	YIB01-0UR
Pipette calibration set	Pipette calibration set, hardware and software for all ME models (0.1 mg and 0.01 mg readability)	YCP03-1
Pipette calibration set	Pipette calibration software	YCP03-2
Rechargeable battery pack	External rechargeable battery pack for balances with a weighing capacity up to ... - Series CP: 8.2 kg - Series LE: 10.2 kg - Series ED: all models - Series ME: all models - Series SE: all models	YRB05Z
Remote display	Remote display LCD; height of digits; 13 mm; reflective	YRD02Z
Software	SartoConnect, data transfer software, for direct input of weighing data into an application program (e.g., such as Excel) with RS232C standard cable, length: 1 m	YSC01L
Software	SartoConnect, data transfer software, for direct input of weighing data into an application program (e.g., such as Excel) with RS232C standard cable, length: 15 m	YSC01L15
Software	SartoConnect, data transfer software, for direct input of weighing data into an application program (e.g., such as Excel) with RS232C standard cable, length: 5 m	YSC01L5
Standard Operating Procedure (SOP)	Standard Operating Procedure (SOP) in German	YSL01D
Standard Operating Procedure (SOP)	Standard Operating Procedure (SOP) in English	YSL01E
Stat pen	Stat pen, unit to neutralize static electricity on samples (100V to 230V, 50/60Hz)	YSTP01
T-connector	T-connector, for connecting two peripheral devices to the balance	YTC01
Weight set	Weight set for determination of the air density, for all ME models (0.1 mg and 0.01 mg readability)	YSS45-00

Sartorius LA Reference Precision Balances

Sartorius LA Reference – gives you what’s really important for accomplishing weighing tasks proficiently.

Reliability without any compromises. Error-free input of data and parameters using ergonomic, tactile keys. Clear readouts on the straightforward, high-contrast graphical display. A metal housing, proprietary monolithic weigh cell technology and a high-grade keypad overlay give the balance the resilience it needs to stand up to tough daily use. The monolithic weigh cell manufactured with the highest level of precision delivers weighing results with the same high precision with the fastest response time. Extensive user support – ideal for complex applications and use in quality management systems.

Special features of the LA analytical balances:

• Fully automatic calibration and adjustment function, isoCAL. Alternatively, calibration times (3 times max.) can be entered at which the balance will be daily calibrated and adjusted.
• ISO/GLP-compliant recording/printouts with memory for up to 50 ISO/GLP-compliant calibration/adjustment records
• Total ease of operation by plain-text prompts; convenient alphanumeric ID input capability
• SQmin function for displaying the allowable minimum sample weight according to the United States Pharmacopeia (activated by Sartorius Service)
• Continuous display of the measurement uncertainty according to the German Calibration Service DKD (activated by Sartorius Service)
• Built-in application programs: density determination, statistics, calculation by a factor, animal weighing and weigh averaging for extremely unstable conditions, ± weighing, counting (with optimized reference sample updating), net-total formulation, weighing in percent



Model
Readability	Capacity	Pan Size	Calibration	Model
Standard models
0.001 g	1200 g	Ø 130 mm	intern	LA1200S
0.001 g	620 g	Ø 130 mm	intern	LA620S
0.001 g	220 g	Ø 130 mm	intern	LA220S
0.001/0.01 g	1010 / 2000 g	Ø 130 mm	intern	LA2000P
0.001/0.002/0.005 g	120 / 240 / 620 g	Ø 130 mm	intern	LA620P
0.001/0.01 g	1010 / 5200 g	Ø 130 mm	intern	LA5200D
0.001/0.01 g	1000 / 3200 g	Ø 130 mm	intern	LA3200D
0.01 g	8200 g	216x200 mm	intern	LA8200S
0.01 g	6200 g	216x200 mm	intern	LA6200S
0.01 g	4200 g	216x200 mm	intern	LA4200S
0.01 g	2200 g	216x200 mm	intern	LA2200S
0.01 g	820 g	216x200 mm	intern	LA820
0.01 g	420 g	216x200 mm	intern	LA420
0.01/0.02/0.05 g	2000/4000/8200 g	216x200 mm	intern	LA8200P
0.01/0.02/0.05/ 0.1 g	1200/2400/3600/5200 g	216x200 mm	intern	LA5200P
0.01/0.02/0.1 g	400 / 800 / 2200 g	216x200 mm	intern	LA2200P
0.1 g	64000 g	300x400 mm	intern	LA64001S
0.1 g	34000 g	300x400 mm	intern	LA34001S
0.1 g	16000 g	300x400 mm	intern	LA16001S
0.1 g	12000 g	216x200 mm	intern	LA12000S
0.1 g	6200 g	216x200 mm	intern	LA6200
0.1 g	4200 g	216x200 mm	intern	LA4200
0.1 g	2200 g	216x200 mm	intern	LA2200
0.1/0.2/0.5 g	8000/16000/34000 g	300x400 mm	intern	LA34001P
0.1/ 0.2/ 0.5 g	3000/6000/12000 g	216x200 mm	intern	LA12000P
1 g	34000 g	300x400 mm	intern	LA34000
Verified models with EC type approval
0.001 g	0.1 - 1200 g	Ø 130 mm	intern	LA1200S-0CE
0.001 g	0.02 - 620 g	Ø 130 mm	intern	LA620S-0CE
0.001 g	0.02 - 220 g	Ø 130 mm	intern	LA220S-0CE
0.001/0.002/0.005 g	0.02 - 620 g	Ø 130 mm	intern	LA620P-0CE
0.01 g	0.5 - 8200 g	218x200 mm	intern	LA8200S-0CE
0.01 g	0.5 - 6200 g	216x200 mm	intern	LA6200S-0CE
0.01 g	0.5 - 4200 g	216x200 mm	intern	LA4200S-0CE
0.01 g	0.5 - 2200 g	216x200 mm	intern	LA2200S-0CE
0.01 g	0.5 - 820 g	216x200 mm	intern	LA820-0CE
0.01/0.02/0.05 g	0.5 - 8200 g	218x200 mm	intern	LA8200P-0CE
0.01/0.02/0.05/ 0.1 g	0.5 - 5200 g	216x200 mm	intern	LA5200P-0CE
0.01/0.02/0.1 g	0.5 - 2200 gg	216x200 mm	intern	LA2200P-0CE
0.1 g	5 - 34000 g	300x400 mm	intern	LA34001S-0CE
0.1 g	5 - 16000 g	300x400 mm	intern	LA16001S-0CE
0.1 g	5 - 12000 g	216x200 mm	intern	LA12000S-0CE
0.1 g	5 - 6200 g	216x200 mm	intern	LA6200-0CE
0.1 g	5 - 2200 g	216x200 mm	intern	LA2200-0CE
0.1/0.2/0.5 g	5 - 34000 g	300x400 mm	intern	LA34001P-0CE
0.1/ 0.2/ 0.5 g	5 - 12000 g	216x200 mm	intern	LA12000P-0CE
1 g	50 - 34000 g	300x400 mm	intern	LA34000-0CE



Accessories
Group	Description	Order-Nr.
Analytical draft shield	Draft shield chamber with sliding doors, for 1-mg LA models	YDS01LP
Bar code scanner	Bar code scanner, for SE2, all LA and ME models (YCC01-0024M01 required)	YBR02FC
Bar code scanner	Cable for connecting the bar code scanner	YCC01-0024M01
Carrying case	Carrying case, for all LA models, up to 12.1 kg	YDB01LP
Check weighing display	3-segment check weighing display, red/green/red, for over/under check weighing (light/heavy); incl. T-connector	YRD11Z
Data printer	Ink ribbon cartridge, for YDP03-OCE	6906918
Data printer	Paper rolls, for YDP03-OCE; 5 units, each with 50 m	6906937
Data printer	Data printer, suitable for use in legal metrology; with date, time, statistics and transaction counter functions	YDP03-0CE
Density determination kit	Density determination kit, for all 1-mg LA models, LE models LE324S, LE244S and ED models ED224S and ED124S	YDK01LP
Extension cable	Cable for connecting the weighing cell to a separate display and control unit (length:2.70 m), for LA models with a weighing capacity = 64 kg	YCC01-19M3
Flow Rate Controller	Flow Rate Controller, for pumps and feed units with analog or pulse interfaces	YFC02Z-V2
Foot switch	Foot switch, for activating the print, tare or F key; function can be selected by menu code; incl. T-connector for series CP, ED, LA, LE and TE	YFS01
Hand switch	Hand switch, for activating the print, tare or F key; function can be selected by menu code; incl. T-connector	YHS02
Interface cable	RS-232C interface cable, for connecting the balance to a PC with a 25-pin COM port; length approx. 1.5 m	7357312
Interface cable	RS-232C interface cable, for connecting the balance to a PC with a 9-pin COM port; length approx. 1.5 m	7357314
Interface cable	RS-232/USB connecting cable (length: approx. 1.8 m); CD with software drivers for installation under Windows 98/ME/2000/XP	YCC01-USBM2
Ionizing blower	Ionizing blower (220V) for electrostatically charged samples	YIB01-0DR
Ionizing blower	Ionizing blower (110V) for electrostatically charged samples	YIB01-0UR
Rechargeable battery pack	External rechargeable battery pack for balances with a weighing capacity up to ... - Series CP: from 12 kg up to 34 kg - Series LA: all models - Series LE: from 16 kg up to 34 kg	YRB06Z
Remote display	Remote display LCD; height of digits; 13 mm; reflective	YRD02Z
Software	SartoConnect, data transfer software, for direct input of weighing data into an application program (e.g., such as Excel) with RS232C standard cable, length: 1 m	YSC01L
Software	SartoConnect, data transfer software, for direct input of weighing data into an application program (e.g., such as Excel) with RS232C standard cable, length: 15 m	YSC01L15
Software	SartoConnect, data transfer software, for direct input of weighing data into an application program (e.g., such as Excel) with RS232C standard cable, length: 5 m	YSC01L5
Standard Operating Procedure (SOP)	Standard Operating Procedure (SOP) in German	YSL01D
Standard Operating Procedure (SOP)	Standard Operating Procedure (SOP) in English	YSL01E
Stat pen	Stat pen, unit to neutralize static electricity on samples (100V to 230V, 50/60Hz)	YSTP01
Support arm	Support arm, for raised display configuration for LA models with a weighing capacity = 12 kg	YDH01LP
Support arm	Support arm, for raised display configuration for LA models with a weighing capacity = 16 kg	YDH02LP
T-connector	T-connector, for connecting two peripheral devices to the balance	YTC01
Weighing bowls	Weighing bowl: Made of chrome nickel steel; without pouring spout; 1,000 ml capacity for balances with a weighing capacity > 300 g	641211
Weighing bowls	Weighing bowl: Made of chrome nickel steel; without pouring spout; 500 ml capacity	641212

Sartorius LA Reference Analytical Balances



Sartorius LA Reference – gives you what’s really important for accomplishing weighing tasks proficiently.

Reliability without any compromises. Error-free input of data and parameters using ergonomic, tactile keys. Clear readouts on the straightforward, high-contrast graphical display. A metal housing, proprietary monolithic weigh cell technology and a high-grade keypad overlay give the balance the resilience it needs to stand up to tough daily use. The monolithic weigh cell manufactured with the highest level of precision delivers weighing results with the same high precision with the fastest response time. Extensive user support – ideal for complex applications and use in quality management systems.

Special features of the LA analytical balances:

• Fully automatic calibration and adjustment function, isoCAL. Alternatively, calibration times (3 times max.) can be entered at which the balance will be daily calibrated and adjusted.
• ISO/GLP-compliant recording/printouts with memory for up to 50 ISO/GLP-compliant calibration/adjustment records
• Total ease of operation by plain-text prompts; convenient alphanumeric ID input capability
• SQmin function for displaying the allowable minimum sample weight according to the United States Pharmacopeia (activated by Sartorius Service)
• Continuous display of the measurement uncertainty according to the German Calibration Service DKD (activated by Sartorius Service)
• Especially large draft shield chamber with optimally accessible weighing pan
• “Cool” display technology – minimizes the effect of heat on the microclimate inside the draft shield chamber on analytical balances
• Built-in application programs: density determination, statistics, calculation by a factor, animal weighing and weigh averaging for extremely unstable conditions, ± weighing, counting (with optimized reference sample updating), net-total formulation, weighing in percent



Model
Readability	Capacity	Pan Size	Calibration	Model
Standard models
0.1 mg	310 g	Ø 90 mm	intern	LA310S
0.1 mg	230 g	Ø 90 mm	intern	LA230S
0.1 mg	150 g	208x264 mm	intern	LA130S-F
0.1 mg	120 g	Ø 90 mm	intern	LA120S
0.1/0.2/0.5 mg	60/120/230 g	Ø 90 mm	intern	LA230P
Verified models with EC type approval
0.1 mg	0.01 - 310 g	Ø 90 mm	intern	LA310S-0CE
0.1 mg	0.01 - 230 g	Ø 90 mm	intern	LA230S-0CE
0.1 mg	0.01 - 120 g	Ø 90 mm	intern	LA120S-0CE
0.1/0.2/0.5 mg	0.01 - 230 g	Ø 90 mm	intern	LA230P-0CE



Accessories
Group	Description	Order-Nr.
		YDK01-0D
Antistatic weighing pan	Antistatic weighing pan for LA models with a readability of 0.1 mg	YWP01LA
Balance table / Wall console	Balance table, for precise, reliable weighing operations	YWT01
Balance table / Wall console	Balance table, cast stone with damping device	YWT03
Balance table / Wall console	Wall console	YWT04
Bar code scanner	Bar code scanner, for SE2, all LA and ME models (YCC01-0024M01 required)	YBR02FC
Bar code scanner	Cable for connecting the bar code scanner	YCC01-0024M01
Carrying case	Carrying case for all LA models with a readability of 0.1 mg	YDB01LA
Check weighing display	3-segment check weighing display, red/green/red, for over/under check weighing (light/heavy); incl. T-connector	YRD11Z
Data printer	Ink ribbon cartridge, for YDP03-OCE	6906918
Data printer	Paper rolls, for YDP03-OCE; 5 units, each with 50 m	6906937
Data printer	Data printer, suitable for use in legal metrology; with date, time, statistics and transaction counter functions	YDP03-0CE
Density determination kit	Density determination kit for - CP225D, CP324S, CP224S, CP124S - all ME models (0.1 mg and 0.01 mg readability) and LA models (0.1 mg readability) - LE225D	YDK01
Extension cable	Cable for connecting the weighing cell to a separate display and control unit (length:2.70 m), for LA models with a weighing capacity = 64 kg	YCC01-19M3
Foot switch	Foot switch, for activating the print, tare or F key; function can be selected by menu code; incl. T-connector for series CP, ED, LA, LE and TE	YFS01
Hand switch	Hand switch, for activating the print, tare or F key; function can be selected by menu code; incl. T-connector	YHS02
Interface cable	RS-232C interface cable, for connecting the balance to a PC with a 25-pin COM port; length approx. 1.5 m	7357312
Interface cable	RS-232C interface cable, for connecting the balance to a PC with a 9-pin COM port; length approx. 1.5 m	7357314
Interface cable	RS-232/USB connecting cable (length: approx. 1.8 m); CD with software drivers for installation under Windows 98/ME/2000/XP	YCC01-USBM2
Ionizing blower	Ionizing blower (220V) for electrostatically charged samples	YIB01-0DR
Ionizing blower	Ionizing blower (110V) for electrostatically charged samples	YIB01-0UR
Rechargeable battery pack	External rechargeable battery pack for balances with a weighing capacity up to ... - Series CP: from 12 kg up to 34 kg - Series LA: all models - Series LE: from 16 kg up to 34 kg	YRB06Z
Remote display	Remote display LCD; height of digits; 13 mm; reflective	YRD02Z
Software	SartoConnect, data transfer software, for direct input of weighing data into an application program (e.g., such as Excel) with RS232C standard cable, length: 1 m	YSC01L
Software	SartoConnect, data transfer software, for direct input of weighing data into an application program (e.g., such as Excel) with RS232C standard cable, length: 15 m	YSC01L15
Software	SartoConnect, data transfer software, for direct input of weighing data into an application program (e.g., such as Excel) with RS232C standard cable, length: 5 m	YSC01L5
Standard Operating Procedure (SOP)	Standard Operating Procedure (SOP) in German	YSL01D
Standard Operating Procedure (SOP)	Standard Operating Procedure (SOP) in English	YSL01E
Stat pen	Stat pen, unit to neutralize static electricity on samples (100V to 230V, 50/60Hz)	YSTP01
Support arm	Support arm, for raised display configuration for LA models with a weighing capacity = 12 kg	YDH01LP
T-connector	T-connector, for connecting two peripheral devices to the balance	YTC01
Weighing scoop	Weighing scoop: Made of chrome-nickel steel, 90 mm x 32 mm x 8 mm; for LA120S, LA230S, LA230P and LA310S	641214





Sartorius High Capacity Micro ME Balances

Sartorius ME36S Premium Microbalance

This new ME36S microbalance features an exceptionally high weighing capacity of 31g and a readability of 1µg. The ME36S is designed for weighing the smallest sample quantities even in relatively heavy or bulky sample containers. The separate installation of weighing unit and display and/or electronic unit not only reduces thermal disturbances, but also delivers absolutely reliable weighing results. By virtue of its unique design, the ME36S display and weighing units are close enough for ideal operating convenience, with optimal spacing for ergonomic handling of microscopic sample quantities.

The most important performance features of the ME36S:

• Flexible draft shield system with three independently motorized draft shield elements for fully automatic, intuitive operating at the press of a key.
• Large, palm-activated keys with an intelligent learning function for user-friendly operation of the draft shield
• Backlit, graphical display for consistently bright weight readouts.
• Text prompts in plain English (and your choice of other languages) guide you quickly and confidently in configuring the balance.
• The SQmin function displays the minimum allowable sample weight in accordance with the United States Pharmacopeia (can be activated by Sartorius Service)
• S.U.R.E. function for dynamic display of the uncertainty of measurement and process accuracy in accordance with German Calibration Service (DKD) standards for continuous monitoring during all weighing routines (this function is activated by Sartorius Service)
• isoCAL: fully automatic calibration/adjustment function with memory for calibration records
• ISO|GLP-compliant, user-configurable records
• Input capability for alphanumeric sample Ids
• 14 built-in application programs as standard features, such as differential weighing program for up to 999 samples, statistical evaluation, calculation of weights using a definable factor or equation, air density determination.
• Bidirectional RS-232C data interface and additional interface for Sartorius data printer.



Model
Readability	Capacity	Pan Size	Calibration	Model
Standard models
0.001 mg	31 g	Ø 30 mm	intern	ME36S
Verified models with EC type approval
0.001 mg	0.1 mg - 31 g	Ø 30 mm	intern	ME36S-0CE



Accessories
Group	Description	Order-Nr.
Balance table / Wall console	Balance table, for precise, reliable weighing operations	YWT01
Balance table / Wall console	Balance table, cast stone with damping device	YWT03
Balance table / Wall console	Wall console	YWT04
Bar code scanner	Bar code scanner, for SE2, all LA and ME models (YCC01-0024M01 required)	YBR02FC
Bar code scanner	Cable for connecting the bar code scanner	YCC01-0024M01
Data interface	Data interface, PC-compatible (9-pin COM port) for all ME models incl. 5-pin connector for bar code scanner	YDO01ME
Data interface	Data interface, RS-485 (12-pin COM port, round) for all ME models incl. 5-pin connector for bar code scanner	YDO02ME
Data printer	Ink ribbon cartridge, for YDP03-OCE	6906918
Data printer	Paper rolls, for YDP03-OCE; 5 units, each with 50 m	6906937
Data printer	Data printer, suitable for use in legal metrology; with date, time, statistics and transaction counter functions	YDP03-0CE
Extension cable	Cable for connecting the weighing cell to a separate display and control unit (length:2.70 m), for all ME models and SE2	YCC01-MED27
Foot switch	Foot switch, incl.T-connector for all ME models and SE2	YPE01RC
Hand switch	Hand switch, for activating the print, tare or F key; function can be selected by menu code; incl. T-connector	YHS02
Interface cable	RS-232C interface cable, for connecting the balance to a PC with a 25-pin COM port; length approx. 1.5 m	7357312
Interface cable	RS-232C interface cable, for connecting the balance to a PC with a 9-pin COM port; length approx. 1.5 m	7357314
Interface cable	RS-232/USB connecting cable (length: approx. 1.8 m); CD with software drivers for installation under Windows 98/ME/2000/XP	YCC01-USBM2
Ionizing blower	Ionizing blower (220V) for electrostatically charged samples	YIB01-0DR
Ionizing blower	Ionizing blower (110V) for electrostatically charged samples	YIB01-0UR
Rechargeable battery pack	External rechargeable battery pack for balances with a weighing capacity up to ... - Series CP: 8.2 kg - Series LE: 10.2 kg - Series ED: all models - Series ME: all models - Series SE: all models	YRB05Z
Remote display	Remote display LCD; height of digits; 13 mm; reflective	YRD02Z
Software	SartoConnect, data transfer software, for direct input of weighing data into an application program (e.g., such as Excel) with RS232C standard cable, length: 1 m	YSC01L
Software	SartoConnect, data transfer software, for direct input of weighing data into an application program (e.g., such as Excel) with RS232C standard cable, length: 15 m	YSC01L15
Software	SartoConnect, data transfer software, for direct input of weighing data into an application program (e.g., such as Excel) with RS232C standard cable, length: 5 m	YSC01L5
Standard Operating Procedure (SOP)	Standard Operating Procedure (SOP) in German	YSL01D
Standard Operating Procedure (SOP)	Standard Operating Procedure (SOP) in English	YSL01E
Stat pen	Stat pen, unit to neutralize static electricity on samples (100V to 230V, 50/60Hz)	YSTP01
T-connector	T-connector, for connecting two peripheral devices to the balance	YTC01



Sartorius Extend ED Precision Balances



Sartorius Extend precision balances/ ED models. The new high achievers in lab routines.

The new Sartorius Extend series has been specially developed to enable you to cope effectively and reliably with daily routine lab tasks. Powerful technology, application-oriented operation and features, combined with high quality and workmanship, make the Sartorius Extend an indispensable tool that you can depend on, day in and day out.

If you add up all the features, Sartorius Extend offers you advantages that pay for themselves time and again, every day. The balances come standard with the following performance features, among others:

• backlit, high-contrast display with 15 mm digits; exceptionally easy to read under any room lighting conditions
• New operating concept: easy configuration of the individual settings guided by short, menu-driven text prompts (choice of 5 languages) and simple navigation using cursor keys
• Built-in, motorized calibration weight: max. weighing accuracy and max. ease of operation at the touch of a key. These are standard on all precision balances ED...-CW
• RS-232C bidirectional interface port; optional Sartorius cable for connection of the balance to a USB port
• The most advanced microprocessor technology. More performance power, for even faster and more stable readings
• Built-in application programs: calculation by a factor (multiplication and division), toggling among up to 4 different units of measure, dynamic weighing / animal weighing (weigh averaging), weighing in percent, net-total formulation, parts counting, totalizing



Model
Readability	Capacity	Pan Size	Calibration	Model
Standard models
0.001 g	620 g	Ø 115 mm	extern	ED623S
0.001 g	620 g	Ø 115 mm	intern	ED623S-CW
0.001 g	420 g	Ø 115 mm	extern	ED423S
0.001 g	420 g	Ø 115 mm	intern	ED423S-CW
0.001 g	320 g	Ø 115 mm	extern	ED323S
0.001 g	320 g	Ø 115 mm	intern	ED323S-CW
0.001 g	150 g	Ø 115 mm	extern	ED153
0.001 g	150 g	Ø 115 mm	intern	ED153-CW
0.01 g	6200 g	180x180 mm	extern	ED6202S
0.01 g	6200 g	180x180 mm	intern	ED6202S-CW
0.01 g	4200 g	180x180 mm	extern	ED4202S
0.01 g	4200 g	180x180 mm	intern	ED4202S-CW
0.01 g	3200g	180x180 mm	extern	ED3202S
0.01 g	3200g	180x180 mm	intern	ED3202S-CW
0.01 g	2200 g	180x180 mm	extern	ED2202S
0.01 g	2200 g	180x180 mm	intern	ED2202S-CW
0.01 g	820 g	Ø 150 mm	extern	ED822
0.01 g	820 g	Ø 150 mm	intern	ED822-CW
0.1 g	8200 g	180x180 mm	extern	ED8201
0.1 g	8200 g	180x180 mm	intern	ED8201-CW
0.1 g	5200 g	180x180 mm	extern	ED5201
0.1 g	5200 g	180x180 mm	intern	ED5201-CW
0.1 g	2200 g	180x180 mm	extern	ED2201
0.1 g	2200 g	180x180 mm	intern	ED2201-CW
Verified models with EC type approval
0.001 g	0.02 - 620 g	Ø 115 mm	intern	ED623S-0CE
0.001 g	0.02 - 420 g	Ø 115 mm	intern	ED423S-0CE
0.001 g	0.02 - 320 g	Ø 115 mm	intern	ED323S-0CE
0.001 g	0.02 - 150 g	Ø 115 mm	intern	ED153-0CE
0.01 g	0.5 - 6200 g	180x180 mm	intern	ED6202S-0CE
0.01 g	0.5 - 4200 g	180x180 mm	intern	ED4202S-0CE
0.01 g	0.5 - 3200g	180x180 mm	intern	ED3202S-0CE
0.01 g	0.5 - 2200 g	180x180 mm	intern	ED2202S-0CE
0.01 g	0.5 - 820 g	180x180 mm	intern	ED822-0CE
0.1 g	5 - 8200 g	180x180 mm	intern	ED8201-0CE
0.1 g	5 - 5200 g	180x180 mm	intern	ED5201-0CE
0.1 g	5 - 2200 g	180x180 mm	intern	ED2201-0CE



Accessories
Group	Description	Order-Nr.
Data printer	Ink ribbon cartridge, for YDP03-OCE	6906918
Data printer	Paper rolls, for YDP03-OCE; 5 units, each with 50 m	6906937
Data printer	Data printer, suitable for use in legal metrology; with date, time, statistics and transaction counter functions	YDP03-0CE
Foot switch	Foot switch, for activating the print, tare or F key; function can be selected by menu code; incl. T-connector for series CP, ED, LA, LE and TE	YFS01
Hand switch	Hand switch, for activating the print, tare or F key; function can be selected by menu code; incl. T-connector	YHS02
Interface cable	RS-232C interface cable, for connecting the balance to a PC with a 25-pin COM port; length approx. 1.5 m	7357312
Interface cable	RS-232C interface cable, for connecting the balance to a PC with a 9-pin COM port; length approx. 1.5 m	7357314
Interface cable	RS-232/USB connecting cable (length: approx. 1.8 m); CD with software drivers for installation under Windows 98/ME/2000/XP	YCC01-USBM2
Ionizing blower	Ionizing blower (220V) for electrostatically charged samples	YIB01-0DR
Ionizing blower	Ionizing blower (110V) for electrostatically charged samples	YIB01-0UR
Rechargeable battery pack	External rechargeable battery pack for balances with a weighing capacity up to ... - Series CP: 8.2 kg - Series LE: 10.2 kg - Series ED: all models - Series ME: all models - Series SE: all models	YRB05Z
Remote display	Remote display LCD; height of digits; 13 mm; reflective	YRD02Z
Software	SartoConnect, data transfer software, for direct input of weighing data into an application program (e.g., such as Excel) with RS232C standard cable, length: 1 m	YSC01L
Software	SartoConnect, data transfer software, for direct input of weighing data into an application program (e.g., such as Excel) with RS232C standard cable, length: 15 m	YSC01L15
Software	SartoConnect, data transfer software, for direct input of weighing data into an application program (e.g., such as Excel) with RS232C standard cable, length: 5 m	YSC01L5
Standard Operating Procedure (SOP)	Standard Operating Procedure (SOP) in German	YSL01D
Standard Operating Procedure (SOP)	Standard Operating Procedure (SOP) in English	YSL01E
Stat pen	Stat pen, unit to neutralize static electricity on samples (100V to 230V, 50/60Hz)	YSTP01
T-connector	T-connector, for connecting two peripheral devices to the balance	YTC01
Weighing bowls	Weighing bowl: Made of chrome nickel steel; without pouring spout; 1,000 ml capacity for balances with a weighing capacity > 300 g	641211
Weighing bowls	Weighing bowl: Made of chrome nickel steel; without pouring spout; 500 ml capacity	641212

Sartorius Extend ED Balances

Sartorius Extend analytical balances/ ED models. The new high achievers in lab routines.

The new Sartorius Extend series has been specially developed to enable you to cope effectively and reliably with daily routine lab tasks. Powerful technology, application-oriented operation and features, combined with high quality and workmanship, make the Sartorius Extend an indispensable tool that you can depend on, day in and day out.

If you add up all the features, Sartorius Extend offers you advantages that pay for themselves time and again, every day. The balances come standard with the following performance features, among others:

• backlit, high-contrast display with 15 mm digits; exceptionally easy to read under any room lighting conditions
• New operating concept: easy configuration of the individual settings guided by short, menu-driven text prompts (choice of 5 languages) and simple navigation using cursor keys
• Large, sturdy and nearly frameless, all-glass draft shield chamber on 0.1-mg models, for optimal viewing of the weighing chamber. The draft shield doors and all stainless steel parts of the weighing chamber base are easy to remove in just a few steps for cleaning.
• Built-in, motorized calibration weight: max. weighing accuracy and max. ease of operation at the touch of a key.
• RS-232C bidirectional interface port; optional Sartorius cable for connection of the balance to a USB port
• Total ease of operation. All keys have positive click action. Clearly structured control panel.



Model
Readability	Capacity	Pan Size	Calibration	Model
Standard models
0.1 mg	220 g	Ø 90 mm	intern	ED224S
0.1 mg	120 g	Ø 90 mm	intern	ED124S
Verified models with EC type approval
0.1 mg	0.01 - 220 g	Ø 90 mm	intern	ED224S-0CE
0.1 mg	0.01 - 120 g	Ø 90 mm	intern	ED124S-0CE



Accessories
Group	Descripion	Order-Nr.
Balance table / Wall console	Balance table, for precise, reliable weighing operations	YWT01
Balance table / Wall console	Balance table, cast stone with damping device	YWT03
Balance table / Wall console	Wall console	YWT04
Data printer	Ink ribbon cartridge, for YDP03-OCE	6906918
Data printer	Paper rolls, for YDP03-OCE; 5 units, each with 50 m	6906937
Data printer	Data printer, suitable for use in legal metrology; with date, time, statistics and transaction counter functions	YDP03-0CE
Density determination kit	Density determination kit, for all 1-mg LA models, LE models LE324S, LE244S and ED models ED224S and ED124S	YDK01LP
Foot switch	Foot switch, for activating the print, tare or F key; function can be selected by menu code; incl. T-connector for series CP, ED, LA, LE and TE	YFS01
Hand switch	Hand switch, for activating the print, tare or F key; function can be selected by menu code; incl. T-connector	YHS02
Interface cable	RS-232C interface cable, for connecting the balance to a PC with a 25-pin COM port; length approx. 1.5 m	7357312
Interface cable	RS-232C interface cable, for connecting the balance to a PC with a 9-pin COM port; length approx. 1.5 m	7357314
Interface cable	RS-232/USB connecting cable (length: approx. 1.8 m); CD with software drivers for installation under Windows 98/ME/2000/XP	YCC01-USBM2
Ionizing blower	Ionizing blower (220V) for electrostatically charged samples	YIB01-0DR
Ionizing blower	Ionizing blower (110V) for electrostatically charged samples	YIB01-0UR
Rechargeable battery pack	External rechargeable battery pack for balances with a weighing capacity up to ... - Series CP: 8.2 kg - Series LE: 10.2 kg - Series ED: all models - Series ME: all models - Series SE: all models	YRB05Z
Remote display	Remote display LCD; height of digits; 13 mm; reflective	YRD02Z
Software	SartoConnect, data transfer software, for direct input of weighing data into an application program (e.g., such as Excel) with RS232C standard cable, length: 1 m	YSC01L
Software	SartoConnect, data transfer software, for direct input of weighing data into an application program (e.g., such as Excel) with RS232C standard cable, length: 15 m	YSC01L15
Software	SartoConnect, data transfer software, for direct input of weighing data into an application program (e.g., such as Excel) with RS232C standard cable, length: 5 m	YSC01L5
Standard Operating Procedure (SOP)	Standard Operating Procedure (SOP) in German	YSL01D
Standard Operating Procedure (SOP)	Standard Operating Procedure (SOP) in English	YSL01E
Stat pen	Stat pen, unit to neutralize static electricity on samples (100V to 230V, 50/60Hz)	YSTP01
T-connector	T-connector, for connecting two peripheral devices to the balance	YTC01

Sartorius Expert LE Precision Balances



Sartorius Expert. Strong signals for the laboratory

The Sartorius Expert series, called LE for short, offers premium technology at attractive conditions. Just one “expert” glance at the appealing, high-quality design is bound to convince you – from the display to the weighing pan. You’re looking at 16 precision Expert balances. They are the next generation of advanced technology based on the proven concept of the Sartorius Competence series.

Last but not least, they offer an incredible price | performance ratio.

• Backlit display with 16.5 mm digits (model LE225D without backlighting)
• On 0.001-g models, glass draft shield with removable side panels and hinged cover
• Models LE1003P and LE1003S are supplied with the LE analytical draft shield as standard.
• Bidirectional RS-232C interface port
• Fully automatic calibration and adjustment function, isoCAL
• Application programs: weighing in %, net total formulation, dynamic weighing, animal weighing (weigh averaging), mass unit conversion by toggling, counting



Model
Readability	Capacity	Pan Size	Calibration	Model
Standard models
0.001 g	1010 g	Ø 110 mm	intern	LE1003S
0.001 g	620 g	Ø 110 mm	intern	LE623S
0.001 g	320 g	Ø 110 mm	intern	LE323S
0.001/0.01 g	500 / 1010 g	Ø 110 mm	intern	LE1003P
0.001/0.002/0.005 g	120 / 240 / 620 g	Ø 110 mm	intern	LE623P
0.01 g	6200 g	190x204 mm	intern	LE6202S
0.01 g	5200 g	Ø 130 mm	intern	LE5202S-DS
0.01 g	4200 g	190x204 mm	intern	LE4202S
0.01 g	2200 g	190x204 mm	intern	LE2202S
0.01 g	2200 g	Ø 130 mm	intern	LE2202S-DS
0.01/0.02/0.05 g	1500 / 3000 / 6200 g	190x204 mm	intern	LE6202P
0.1 g	34 kg	300x400 mm	intern	LE34001S
0.1 g	16 kg	300x400 mm	intern	LE16001S
0.1 g	10000 g	190x204 mm	intern	LE10001
0.1 g	5200 g	190x204 mm	intern	LE5201
0.1/0.2/0.5 g	8 / 16 / 34 kg	300x400 mm	intern	LE34001P
Verified models with EC type approval
0.001 g	0.01 - 1000 g	Ø 110 mm	intern	LE1003S-0CE
0.001 g	0.02 - 620 g	Ø 110 mm	intern	LE623S-0CE
0.001 g	0.02 - 320 g	Ø 110 mm	intern	LE323S-0CE
0.001/0.002/0.005 g	0.02 - 620 g	Ø 110 mm	intern	LE623P-0CE
0.01 g	0.5 - 6200 g	190x204 mm	intern	LE6202S-0CE
0.01 g	0.5 - 4200 g	190x204 mm	intern	LE4202S-0CE
0.01 g	0.5 - 2200 g	190x204 mm	intern	LE2202S-0CE
0.01/0.02/0.05 g	0.5 - 6200 g	190x204 mm	intern	LE6202P-0CE
0.1 g	5 g - 34 kg	300x400 mm	intern	LE34001S-0CE
0.1 g	5 g - 16 kg	300x400 mm	intern	LE16001S-0CE
0.1 g	5 - 10000 g	190x204 mm	intern	LE10001-0CE
0.1 g	5 - 5200 g	190x204 mm	intern	LE5201-0CE
0.1/0.2/0.5 g	5 g - 34 kg	300x400 mm	intern	LE34001P-0CE



Accessories
Group	Description	Order-Nr.
Analytical draft shield	Analytical draft shield for - CP423S, CP323S, CP323P, CP153 - LE623S, LE323S, LE623P	YDS01CP
Carrying case	Carrying case, for - CP225D, CP324S, CP224S, CP124S, CP64 - LE225D, LE324S, LE244S, LE1003P, LE1003S, LE5202S-DS, LE2202S-DS	YDB01CP
Carrying case	Carrying case, for - CP423S, CP323S, CP323P, CP153, CP4202S, CP3202S, CP2202S, CP3202P, CP8201, CP6201, CP4201, CP2201 - LE623S, LE323S, LE623P, LE6202S, LE4202S, LE2202S, LE6202P, LE5201, LE10001	YDB02CP
Data printer	Ink ribbon cartridge, for YDP03-OCE	6906918
Data printer	Paper rolls, for YDP03-OCE; 5 units, each with 50 m	6906937
Data printer	Data printer, suitable for use in legal metrology; with date, time, statistics and transaction counter functions	YDP03-0CE
Draft shield cover	Draft shield cover with opening for - CP423S, CP323S, CP153, CP323P - LE623S. LE623P, LE323S	YDS02CP
Foot switch	Foot switch, for activating the print, tare or F key; function can be selected by menu code; incl. T-connector for series CP, ED, LA, LE and TE	YFS01
Hand switch	Hand switch, for activating the print, tare or F key; function can be selected by menu code; incl. T-connector	YHS02
Hanger for below-balance weighing	Hanger for below-balance weighing, screw thread for attachment to - CP34001S, CP16001S, CP12001S, CP34001P, CP34000 - LE34001S, LE16001S, LE34001P	69EA0040
Interface cable	RS-232C interface cable, for connecting the balance to a PC with a 25-pin COM port; length approx. 1.5 m	7357312
Interface cable	RS-232C interface cable, for connecting the balance to a PC with a 9-pin COM port; length approx. 1.5 m	7357314
Interface cable	RS-232/USB connecting cable (length: approx. 1.8 m); CD with software drivers for installation under Windows 98/ME/2000/XP	YCC01-USBM2
Ionizing blower	Ionizing blower (220V) for electrostatically charged samples	YIB01-0DR
Ionizing blower	Ionizing blower (110V) for electrostatically charged samples	YIB01-0UR
Rechargeable battery pack	External rechargeable battery pack for balances with a weighing capacity up to ... - Series CP: 8.2 kg - Series LE: 10.2 kg - Series ED: all models - Series ME: all models - Series SE: all models	YRB05Z
Rechargeable battery pack	External rechargeable battery pack for balances with a weighing capacity up to ... - Series CP: from 12 kg up to 34 kg - Series LA: all models - Series LE: from 16 kg up to 34 kg	YRB06Z
Remote display	Remote display LCD; height of digits; 13 mm; reflective	YRD02Z
Software	SartoConnect, data transfer software, for direct input of weighing data into an application program (e.g., such as Excel) with RS232C standard cable, length: 1 m	YSC01L
Software	SartoConnect, data transfer software, for direct input of weighing data into an application program (e.g., such as Excel) with RS232C standard cable, length: 15 m	YSC01L15
Software	SartoConnect, data transfer software, for direct input of weighing data into an application program (e.g., such as Excel) with RS232C standard cable, length: 5 m	YSC01L5
Standard Operating Procedure (SOP)	Standard Operating Procedure (SOP) in German	YSL01D
Standard Operating Procedure (SOP)	Standard Operating Procedure (SOP) in English	YSL01E
Stat pen	Stat pen, unit to neutralize static electricity on samples (100V to 230V, 50/60Hz)	YSTP01
T-connector	T-connector, for connecting two peripheral devices to the balance	YTC01
Weighing bowls	Weighing bowl: Made of chrome nickel steel; without pouring spout; 1,000 ml capacity for balances with a weighing capacity > 300 g	641211
Weighing bowls	Weighing bowl: Made of chrome nickel steel; without pouring spout; 500 ml capacity	641212

Sartorius Expert LE Balances

Sartorius Expert LE26P : A Microbalance Spanning Two Worlds.

The new Expert LE26P microbalance features an out-of-the-ordinary weighing range structure. Its fine range of 5 g readable to 2 mg can be shifted anywhere within the entire weighing capacity of 21 g that has a coarse readability 10 mg. This means you can use the fine range continuously, even after taring a heavy container and still weigh-in a minimal sample quantity with the higher accuracy, as needed in many applications. The LE26P opens the door to new applications requiring strict compliance with the United States Pharmacopeia requirements. Enabling you to weigh a minimum sample quantity between 5 and 10 mg, attainable depending on the particular installation conditions, the LE26P closes the gap between maximum-resolution microbalances and semi-microbalances.

• Monolithic, 21st century robotically etched weigh cell, now a first in a microbalance featuring this resolution; precise and reliable; rugged design stands up to the rigors of daily lab use
• Built-in, motorized calibration weight. Fully automatic calibration/adjustment at regular intervals performed by the implemented isoCAL function; for maximum reliability when the balance is used in quality systems
• A microbalance with a “macro-sized pan” featuring a diameter of 50 mm; for easy, secure positioning of relatively large sample containers
• Generously sized all-glass draft shield with doors that glide effortlessly and silently, opening wide for convenient sample loading; they offer the best prerequisites for user-friendly weighing of the smallest samples; ample space all around the weighing pan for conditioning samples inside the weighing chamber to the interior temperature
• Conductively coated draft shield doors for reducing the build up of static electricity
• Bidirectional RS-232C data interface
• ISO/GLP-compliant data printouts/records (in combination with the printer YDP03-0CE or PC)
• Built-in application programs: weighing in percent, net-total formulation, dynamic weighing, mass unit conversion by toggling between weight units, counting



Model
Readability	Capacity	Pan Size	Calibration	Model
Standard models
0.002/0.01 mg	5/21 g	Ø 50 mm	intern	LE26P
Verified models with EC type approval
0.002/0.01 mg	0.1 mg - 21 g	Ø 50 mm	intern	LE26P-0CE



Accessories
Group	Description	Order-Nr.
Balance table / Wall console	Balance table, for precise, reliable weighing operations	YWT01
Balance table / Wall console	Balance table, cast stone with damping device	YWT03
Balance table / Wall console	Wall console	YWT04
Data printer	Ink ribbon cartridge, for YDP03-OCE	6906918
Data printer	Paper rolls, for YDP03-OCE; 5 units, each with 50 m	6906937
Data printer	Data printer, suitable for use in legal metrology; with date, time, statistics and transaction counter functions	YDP03-0CE
Foot switch	Foot switch, for activating the print, tare or F key; function can be selected by menu code; incl. T-connector for series CP, ED, LA, LE and TE	YFS01
Hand switch	Hand switch, for activating the print, tare or F key; function can be selected by menu code; incl. T-connector	YHS02
Interface cable	RS-232C interface cable, for connecting the balance to a PC with a 25-pin COM port; length approx. 1.5 m	7357312
Interface cable	RS-232C interface cable, for connecting the balance to a PC with a 9-pin COM port; length approx. 1.5 m	7357314
Interface cable	RS-232/USB connecting cable (length: approx. 1.8 m); CD with software drivers for installation under Windows 98/ME/2000/XP	YCC01-USBM2
Ionizing blower	Ionizing blower (220V) for electrostatically charged samples	YIB01-0DR
Ionizing blower	Ionizing blower (110V) for electrostatically charged samples	YIB01-0UR
Rechargeable battery pack	External rechargeable battery pack for balances with a weighing capacity up to ... - Series CP: 8.2 kg - Series LE: 10.2 kg - Series ED: all models - Series ME: all models - Series SE: all models	YRB05Z
Remote display	Remote display LCD; height of digits; 13 mm; reflective	YRD02Z
Software	SartoConnect, data transfer software, for direct input of weighing data into an application program (e.g., such as Excel) with RS232C standard cable, length: 1 m	YSC01L
Software	SartoConnect, data transfer software, for direct input of weighing data into an application program (e.g., such as Excel) with RS232C standard cable, length: 15 m	YSC01L15
Software	SartoConnect, data transfer software, for direct input of weighing data into an application program (e.g., such as Excel) with RS232C standard cable, length: 5 m	YSC01L5
Standard Operating Procedure (SOP)	Standard Operating Procedure (SOP) in German	YSL01D
Standard Operating Procedure (SOP)	Standard Operating Procedure (SOP) in English	YSL01E
Stat pen	Stat pen, unit to neutralize static electricity on samples (100V to 230V, 50/60Hz)	YSTP01
T-connector	T-connector, for connecting two peripheral devices to the balance	YTC01



Sartorius Expert LE Analytical Balances

Sartorius Expert. Strong signals for the laboratory

The Sartorius Expert series, called LE for short, offers premium at attractive conditions. Just one “expert” glance at the appealing, high-quality design is bound to convince you – from the display to the weighing pan. You’re looking at 3 analytical Expert balances. They are the next generation of advanced technology based on the proven concept of the Sartorius Competence series.

Last but not least, they offer an incredible price | performance ratio.

• Backlit display with 16.5 mm digits (model LE225D without backlighting)
• Tall, all-glass draft shield
• Bidirectional RS-232C interface port
• Fully automatic calibration and adjustment function, isoCAL
• ISO | GLP-compliant recording| printout capability (in combination with the Sartorius YDP03-0CE printer or a PC)



Model
Readability	Capacity	Pan Size	Calibration	Model
Standard models
0.01/ 0.1 mg	100 / 220 g	Ø 80 mm	intern	LE225D
0.1 mg	320 g	Ø 80 mm	intern	LE324S
0.1 mg	240 g	Ø 80 mm	intern	LE244S
Verified models with EC type approval
0.01/0.01/0.1 mg	1 mg - 220 g	Ø 80 mm	intern	LE225D-OCE
0.1 mg	0.01 - 320 g	Ø 80 mm	intern	LE324S-OCE
0.1 mg	0.01 - 240 g	Ø 80 mm	intern	LE244S-OCE



Accessories
Group	Description	Order-Nr.
Antistatic weighing pan	Antistatic weighing pan for - CP225D, CP324S, CP124S, CP224S, CP64 - LE225D	YWP01CP
Antistatic weighing pan	Antistatic weighing pan for LE324S, LE244S	YWP01LE
Balance table / Wall console	Balance table, for precise, reliable weighing operations	YWT01
Balance table / Wall console	Balance table, cast stone with damping device	YWT03
Balance table / Wall console	Wall console	YWT04
Carrying case	Carrying case, for - CP225D, CP324S, CP224S, CP124S, CP64 - LE225D, LE324S, LE244S, LE1003P, LE1003S, LE5202S-DS, LE2202S-DS	YDB01CP
Data printer	Ink ribbon cartridge, for YDP03-OCE	6906918
Data printer	Paper rolls, for YDP03-OCE; 5 units, each with 50 m	6906937
Data printer	Data printer, suitable for use in legal metrology; with date, time, statistics and transaction counter functions	YDP03-0CE
Density determination kit	Density determination kit for - CP225D, CP324S, CP224S, CP124S - all ME models (0.1 mg and 0.01 mg readability) and LA models (0.1 mg readability) - LE225D	YDK01
Density determination kit	Density determination kit, for all 1-mg LA models, LE models LE324S, LE244S and ED models ED224S and ED124S	YDK01LP
Foot switch	Foot switch, for activating the print, tare or F key; function can be selected by menu code; incl. T-connector for series CP, ED, LA, LE and TE	YFS01
Hand switch	Hand switch, for activating the print, tare or F key; function can be selected by menu code; incl. T-connector	YHS02
Interface cable	RS-232C interface cable, for connecting the balance to a PC with a 25-pin COM port; length approx. 1.5 m	7357312
Interface cable	RS-232C interface cable, for connecting the balance to a PC with a 9-pin COM port; length approx. 1.5 m	7357314
Interface cable	RS-232/USB connecting cable (length: approx. 1.8 m); CD with software drivers for installation under Windows 98/ME/2000/XP	YCC01-USBM2
Ionizing blower	Ionizing blower (220V) for electrostatically charged samples	YIB01-0DR
Ionizing blower	Ionizing blower (110V) for electrostatically charged samples	YIB01-0UR
Rechargeable battery pack	External rechargeable battery pack for balances with a weighing capacity up to ... - Series CP: 8.2 kg - Series LE: 10.2 kg - Series ED: all models - Series ME: all models - Series SE: all models	YRB05Z
Remote display	Remote display LCD; height of digits; 13 mm; reflective	YRD02Z
Software	SartoConnect, data transfer software, for direct input of weighing data into an application program (e.g., such as Excel) with RS232C standard cable, length: 1 m	YSC01L
Software	SartoConnect, data transfer software, for direct input of weighing data into an application program (e.g., such as Excel) with RS232C standard cable, length: 15 m	YSC01L15
Software	SartoConnect, data transfer software, for direct input of weighing data into an application program (e.g., such as Excel) with RS232C standard cable, length: 5 m	YSC01L5
Standard Operating Procedure (SOP)	Standard Operating Procedure (SOP) in German	YSL01D
Standard Operating Procedure (SOP)	Standard Operating Procedure (SOP) in English	YSL01E
Stat pen	Stat pen, unit to neutralize static electricity on samples (100V to 230V, 50/60Hz)	YSTP01
T-connector	T-connector, for connecting two peripheral devices to the balance	YTC01

Sartorius Element ELT Budget Balances

The Sartorius Element Series.

This product series is available only in the following countries: Canada, Hong Kong, India, Japan, USA. The Sartorius Element is an entry-level balance for the laboratory, designed for multi-faceted and changing needs. The option of using high-capacity batteries means you can operate the balance independently of a power supply or in a stationary installation. Clear operator guidance features make it easy to adapt the balance to different applications. If the balance needs to be connected to a computer at some later stage, an interface port can be simply plugged into the back panel.

ELT models come with the following performance features as standard equipment:

• Stainless steel weighing pan
• Large, white backlit LCD
• Built-in application programs: counting, totalling, weighing in %, locking in readouts, easy below-balance density determination
• Calibration weights stored inside the housing: models: ELT103, ELT602, ELT402, ELT202, ELT1001, and ELT601
• Four digital filter levels for adaption of the balance to conditions at the place of use
• Battery-operable (eight 1.5V batteries, except model ELT103)
• Prepared for plug-in data interface adapters (YADAP-RS, YADAP-USB)



Model
Readability	Capacity	Pan Size	Calibration	Model
Standard models
0.001 g	100 g	107 mm	extern	ELT103
0.01 g	600 g	140x127 mm	extern	ELT602
0.01 g	400 g	140x127 mm	extern	ELT402
0.01 g	200 g	140x127 mm	extern	ELT202
0.1 g	6000 g	140x127 mm	extern	ELT6001
0.1 g	4000 g	140x127 mm	extern	ELT4001
0.1 g	2000 g	140x127 mm	extern	ELT2001
0.1 g	1000 g	140x127 mm	extern	ELT1001
0.1 g	600 g	140x127 mm	extern	ELT601
1 g	6000 g	140x127 mm	extern	ELT6000



Accessories
Group	Description	Order-Nr.
Data printer	Ink ribbon cartridge, for YDP03-OCE	6906918
Data printer	Paper rolls, for YDP03-OCE; 5 units, each with 50 m	6906937
Data printer	Data printer, suitable for use in legal metrology; with date, time, statistics and transaction counter functions	YDP03-0CE
Ionizing blower	Ionizing blower (220V) for electrostatically charged samples	YIB01-0DR
Ionizing blower	Ionizing blower (110V) for electrostatically charged samples	YIB01-0UR
Locking device	Anti-theft locking device with cable and padlock	LC-1
RS-232C adapter	Interface adapter with cable, for connecting the balance to a PC with a 9-pin COM port; length approx. 1 m; easy plug in	YADAP-RS
Software	SartoConnect, data transfer software, for direct input of weighing data into an application program (e.g., such as Excel) with RS232C standard cable, length: 1 m	YSC01L
Software	SartoConnect, data transfer software, for direct input of weighing data into an application program (e.g., such as Excel) with RS232C standard cable, length: 15 m	YSC01L15
Software	SartoConnect, data transfer software, for direct input of weighing data into an application program (e.g., such as Excel) with RS232C standard cable, length: 5 m	YSC01L5
USB adapter	Interface adapter with cable, for connecting the balance to a PC with a USB port; length approx. 1 m; easy plug in; including PC driver data on CD	YADAP-USB

Denver XP Budget Balances

Compact Balances for all purposes.
2 Years guarantee.

Model	Readability	Capacity	Pan size
XP-300	0,01g	300g	127x178mm
XP-600	0,02g	600g	127x178mm
XP-1500	0,05g	1.500g	127x178mm
XP-3000	0,1g	3.000g	127x178mm

Features

Integrated rechargeable battery

Automatic external calibration

Optional RS232C Interface

Power supply

Denver Ultra Basic pH Meter

        The compact and versatile Ultra Basic Meters offer precision and simple operation with little required space.

Specifications UltraBasic Benchtop Meters


Model UB-5 pH/temp UB-10 pH/mV/temp   pH range 0,00-14,00 0,00-14,00 pH resolution 0,01 0,01 pH accuracy 0,005 pH 0,005 pH mV range - -1800,0-1800,0 mV resolution - 0,1 mV accuracy - 0,2 mV or 0,05% Temperature range 0,0-100,0°C 0,0-100,0°C Temperature resolution 0,1 °C 0,1 °C Temperature accuracy 0,2 °C 0,2 °C     Common Specifications Weight 270 gr   Dimensions (LxWxH) 9,0 x 4,75 x 3,125" (229 x 121 x 79 mm)

UB-Meters are available in four versions:
UB-5A, UB-10A includes Meter and power supply
UB-5, UB-10 includes Meter, pH-combination electrode 301423-1, base with arm 300401-1 and power supply
UB-5, UB-10 Deluxe Kit includes Meter, pH/ATC combination electrode 300728-1, base with arm 300401-1 and power supply
UB-5, UB-10 Deluxe Bio-Kit includes Meter, pH/ATC combination electrode 300729-1, base with arm 300401-1 and power supply



Denver TP Analytical Balances

The TP series sets new standards in the class of economical laboratory balances.
The performance of the TP-line from Denver Instrument featuring easy operation, fast readouts, precision and reliability makes this balance the ideal instrument for laboratory, research and educational environments.

Model	Readability	Capacity	Pan Size	Calibration
TP-214	0,1mg	210g	ø 80mm	external
TP-303	1mg	310g	ø 100mm	external
TP-303i	1mg	310g	ø 100mm	internal
TP-3002	0,01g	3100g	174x143mm	external
TP-1502	0,01g	1500g	174x143mm	external
TP-6101	0,1g	6100g	174x143mm	external
TP-3101	0,1g	3100g	174x143mm	external
TP-12	1g	12000g	174x143mm	external



Features

Affordable price

Quick, exact and fast readouts are guaranteed  with the new weighing technology incorporated in the TP-line

Easy Operation

Internal or external Calibration

Production according ISO-standards ISO 9001:2000 and ISO 14001

3 Years Warranty

Applications

Counting

%-weighing

Formulation

Average Weighing

Weighing in 19 different weigh units

GLP/GMP-protocol can be obtained with an optional printer

Denver Summit Precision Balances

The Quality of this product is exceptional, so much so, we give a 5-year warranty on every Summit Balance.

Model	Readability	Capacity	Pan Size	Calibration
SI-603*	1mg	600g	ø 115mm	internal
SI-403*	1mg	400g	ø 115mm	internal
SI-203*	1mg	200g	ø 115mm	internal
SI-6002*	0,01g	6000g	180x180mm	internal
SI-4002*	0,01g	4000g	180x180mm	internal
SI-2002*	0,01g	2000g	180x180mm	internal
SI-602*	0,01g	600g	ø 115mm	internal
SI-402	0,01g	400g	ø 115mm	internal
SI-8001*	0,1g	8000g	180x180mm	internal
SI-4001*	0,1g	4000g	180x180mm	internal
S-603	1mg	600g	ø 115mm	external
S-403	1mg	400g	ø 115mm	external
S-203	1mg	200g	ø 115mm	external
S-6002	0,01g	6000g	180x180mm	external
S-4002	0,01g	4000g	180x180mm	external
S-2002	0,01g	2000g	180x180mm	external
S-602	0,01g	600g	ø 115mm	external
S-402	0,01g	400g	ø 115mm	external
S-8001	0,1g	8000g	180x180mm	external
S-4001	0,1g	4000g	180x180mm	external



Features

Large, Back-lit Display

Comprehensive Program Library

Standard RS232 Interface allows ISO/GLP conforming Protocol

User Guidance by Short-Text-Terms



Applications

Counting

Weighing in Percent

Net Total (Formulation)

Calculating

Animal Weighing / Averaging

Totalising

Density Determination

Mass Unit Conversion, you can read four units simultaneously, 22 different mass units are available

ISO / GLP conforming Protocol

Hook for Weighing Below

*also available with European Stamp Approval

Denver Stamp Approved TP Analytical Balances

Robust, Reliable - Affordable
European Stamp Approved.

Model	Readability	Capacity	Pan Size	Calibration
TP-214A	0,1mg	210g	ø 80mm	external
TP-124A	0,1mg	120g	ø 80mm	external
TP-512A	0,01g	510g	ø 116mm	internal
TP-1200A	1g	1200g	174x143mm	external



Features

European Stamp Approved

Affordable price

Quick, exact and fast readouts are guaranteed  with the new weighing technology incorporated in the TP-line

Easy Operation

Internal or external Calibration

Production according ISO-standards ISO 9001:2000 and ISO 14001

3 Years Warranty



Applications

Counting

%-weighing

Formulation

Average Weighing

Weighing in 19 different weigh units

GLP/GMP-protocol can be obtained with an optional printer

Denver Portable pH Meters

Rugged and easy-to-use pH-Meters designed to be used in severe conditions.

Specifications UltraBasic Portable Meters

Model UP-5pH/temp UP-10pH/mV/temp UP-25pH/mV/Ion/temp pH range 0,00-14,00 0,00-14,00 0,00-14,00 pH resolution 0,01 0,01 0,01 pH accuracy 0,005 pH 0,005 pH 0,005 pH mV range   -1800,0 -+1800,0 -1800,0 -+1800,0 mV resolution   0,1 0,1 mV accuracy   0,2mV or ±0,5%  0,2mV or ±0,5% Temperature range   0,0-100,0 °C   Temperature resolution  0,1 °C 0,1 °C 0,1 °C Temperature accuracy  0,2 °C 0,2 °C 0,2 °C Ion range     0,0001-99900 Ion resolution     1, 2 or 3 sig figures Ion accuracy     0,34%   Common Specifications Weight 270 gr Dimensions (L x W x H) 6,5 x 4 x 1,3" (16,5 x 10,2 x 3,3 cm)

UP- Meter are available in two versions:
UP-5A, UP-10A und UP-25A includes Meter and 9V battery
UP-5, UP-10 and UP-25 includes pH-combination electrode 301423-1 and 9V battery



Features

Waterproof - IP-67 rated

Rugged and compact

Easy-To-Use

Large Display

3 Calibration Points

Auto-buffer recognition of 16 buffers

Denver Pinnacle PI-403 to PI-603D Precision Balances

Top loading balances without compromises.
Three years long-term guarantee.

Model	Readability	Capacity	Pan size	Calibration
P-403	1mg	400g	ø 114mm	external
PI-403	1mg	400g	ø 114mm	internal
PI-403A	1mg	400g	ø 114mm	internal - stamp approved
P-203	1mg	200g	ø 114mm	external
PI-203	1mg	200g	ø 114mm	internal
PI-203A	1mg	200g	ø 114mm	internal - stamp approved
P-603D	0,001/0,01g	100g/600g	ø 114mm	external
PI-603D	0,001/0,01g	100g/600g	ø 114mm	internal



Features

Calibration time - and temperature-dependent (PI-series)

Calibration external with user-definable weight (P-series)

Stamp Approved (Only PI-403A and PI-203A)

Three communication ports:RS232C, USB and LAN

Software for data transfer to windows applications via USB

User Menu in German, English, Spanish and French

GLP/GMP-compliant protocols

Hook for weighing below

Power supply



Applications

Counting

Weighing in %

Weighing in different weigh units

Formulation

Animal weighing

Target weighing

Control (+/-) weighing

Statistic



Denver Pinnacle PI-114 to PI-314 Analytical Balances

Analytical balances without compromises.
Three years long-term guarantee.

Model	Readability	Capacity	Pan size	Calibration
PI-225DA	0,01/0,1mg	60/220g	ø 90mm	internal Stamp Approved
P-314	0,1mg	310g	ø 80mm	external
PI-314	0,1mg	310g	ø 80mm	internal
PI-314A	0,1mg	310g	ø 80mm	internal Stamp Approved
P-214	0,1mg	210g	ø 80mm	external
PI-214	0,1mg	210g	ø 80mm	internal
PI-214A	0,1mg	210g	ø 80mm	internal Stamp Approved
P-114	0,1mg	110g	ø 80mm	external
PI-114	0,1mg	110g	ø 80mm	internal
PI-114A	0,1mg	110g	ø 80mm	internal Stamp Approved



Features

Calibration time - and temperature-dependent (PI-series)

Calibration external with user-definable weight (P-series)

Stamp Approved (PI-...A series)

Three communication ports:RS232C, USB and LAN

Software for data transfer to windows applications via USB

GLP/GMP-compliant protocols

User Menu in German, English, Spanish and French

Hook for weighing below

Power supply



Applications

Counting

Weighing in %

Weighing in different weigh units

Formulation

Animal weighing

Target weighing

Control (+/-) weighing

Statistic   Denver Pinnacle P-4002 to PI-8002 Precision Balances Top loading balances without compromises. Three years long-term guarantee. Model Readability Capacity Pan size Calibration P-4002 0,01g 4.000g 178x178mm external PI-4002 0,01g 4.000g 178x178mm internal PI-4002A 0,01g 4.000g 178x178mm internal-stamp approved P-2002 0,01g 2.000g 178x178mm external PI-2002 0,01g 2.000g 178x178mm internal PI-2002A 0,01g 2.000g 178x178mm internal-stamp approved P-4002D 0,01/0,1g 400/4.000g 178x178mm external PI-4002D 0,01/0,1g 400/4.000g 178x178mm internal P-8001 0,1g 8.000g 178x178mm external P-6001 0,1g 6.000g 178x178mm external PI-6001 0,1g 6.000g 178x178mm internal PI-6001A 0,1g 6.000g 178x178mm internal-stamp approved P-8002D 0,01/0,1g 800/8.000g 178x178mm external   Features   Calibration time - and temperature-dependent (PI-series) Calibration external with user-definable weight (P-series) Stamp Approved (PI-4002A, PI2002A and PI-6001A only) Three communication ports:RS232C, USB and LAN Software for data transfer to windows applications via USB GLP/GMP-compliant protocols User Menu in German, English, Spanish and French Hook for weighing below Power supply   Applications   Counting Weighing in % Weighing in different weigh units Formulation Animal weighing Target weighing Control (+/-) weighing Statistic Denver Pinnacle P-602 to PI-402 Precision Balances Top loading balances without compromises. Three years long-term guarantee. Model Readability Capacity Pan size Calibration P-602 0,01g 600g ø 114mm external PI-602 0,01g 600g ø 114mm internal PI-602A 0,01g 600g ø 114mm internal - stamp approved P-402 0,01g 400g ø 114mm external PI-402 0,01g 400g ø 114mm internal   Features   Calibration time - and temperature-dependent (PI-series) Calibration external with user-definable weight (P-series) Stamp Approved (PI-602A only) Three communication ports:RS232C, USB and LAN Software for data transfer to windows applications via USB GLP/GMP-compliant protocols User Menu in German, English, Spanish and French Hook for weighing below Power supply   Applications   Counting Weighing in % Weighing in different weigh units Formulation Animal weighing Target weighing Control (+/-) weighing Statistic Denver pH 200 Series pH Meter       Quality for highest demands without compromises. The user is supported perfectly and all the requirements to GMP/GLP/ISO are totally fulfilled.   Modes for each Model PH-215 pH/mV/temp PH-220 pH/mV/temp/conductivity PH-225 pH/mV/temp/ISE PH-250 pH/mV/temp/conductivity/ISE   Modes pH mV Temperature Ranges -2.000 to 20.000 ±2.400 -5,0 to 105,0 °C Resolution 0,001/0,01/0,1 0,1/1 0,1 Accuracy ±0,001 pH ±0,05 mV ±0,1 °C Temp Compensation Automatic and manual: -5 to 105 °C Slope Control Automatic, 90 to 105%; manual, 80 to 110% Environment 15 - 40 °C, 0 - 90% relative humidity Ion Mode (Models 250/225) Range 1,00 x 10-9 to 9,99 x 109 Resolution 1, 2, 3 significant digits Relative accuracy ±0,09 n% Conductivity Mode (Models 250/220) Conductivity Range 0 to 300.000 µs/cm (depending on cell constant) Relative accuracy 0,5% reading Salinity ranges Autoranging, 0.01 to 70ppt NaCl equivalent salinity Autoranging, 0.01 to 42ppt NaCl practical salinity Resistivity 30 Ohm•cm to 1, 10 oder 20 Megohm•cm (at cell constants of 10, 1, 0.5cm-1respectively). Autoranging units; readout in ohm?cm, kilohm?cm, or megohm?cm. Fixed units: kilohm?cm Total dissolved solids 0,005 to 1,5 x 105 mg/L (at 0.5 solids factor, depending on cell constant) Temp coefficient Software configurable; off or on, 0 to 4%/°C   Meter kits includes: Meter, power supply, high performance glass-body pH/ATC electrode 300729-1, electrode arm and operation manual.   Features Large , multifunctional, backlit display Plain language menus Soft Key Help Function 5 Calibration Points Auto-buffer recognition of 27 buffers Storage for up to 620 results RS232 Data Interface Complete GLP/GMP/ISO documentation   Denver Top Pan Balances   Setting a New Standard   Introducing the new T-Series balances from Denver Instrument Company. We've raised the standard at Denver Instrument with the release of the new T-Series balances. These new balances exceed all expectations for accuracy, repeatability and stability--so much so that "new and improved" doesn't begin to cover the enhancements: like all Denver Instrument products, they're amazingly affordable! Standard Features for TR, TL and TC-Series: Simple, menu-driven operation 16 weigh unitsAnimal weighing Parts counting Automatic calibration RS-232C interface  TL and TC-Series Advanced Features:  GLP data storage and output Illuminated display Statistical analysis Fill guide with graphical indicator Check weighing Batch weighing Internal calibration (TC-Series only) Whether you're in the market for a basic toploading balance or a full-featured analytical, look to the new T-Series for the latest advancements in precision weighing technology. From the basic TR-Series to the advanced TL and TC Series, there's a balance for every application and every budget. Plus, they're backed by the most comprehensive warranty in the industry. Simply stated, should any T-Series balance fail to perform to specification within the stated warranty period, it will be replaced or repaired at no charge.   Denver Maxx Budget Balances MAXimum Balance - Minimum Price The MAXX-Series offers high precision up to mg-accuracy and an extensive range of models - all at an unbeatable price. Latest, microprocessor controlled weighing technology guaranties fast and precise results at any time. Also the MAXX-Series includes an extensive range of application programs and easy and comfortable handling, e.g. a back lit display. All these features of the new MAXX-Series, at an unrivalled price. Model Readability Capacity Pan size MXX-123 0,001g          120g          ø 97mm MXX-212 0,01g          210g          ø 97mm MXX-412 0,01g          410g          142x130mm MXX-612 0,01g          610g          142x130mm MXX-601 0,1g          610g          142x130mm MXX-2001 0,1g          2000g          142x130mm MXX-5001 0,1g          5000g          142x130mm MXX-5 1g          5kg          142x130mm MXX-10 1g          10kg          142x130mm   Features   Huge, back lighted display for comfortable readouts Protected foil and large, clearly defined buttons for easy handling Maximum overload protection Stainless steel weighing pan Compact design Simple and logical user guidance Fully-automatic, external Calibration Calibration weight included in MXX-123, MXX-212, MXX-412, MXX-612 AC-adapter or battery operated (MXX-123 power supply only ) AC-adapter included Bi-directional RS-232 or USB interface as an option for easy data communication 2 Year Warranty   Applications   Weighing in 13 different weighing units Toggling between two different weighing units Counting %Weighing Formulation Static Display Determination of specific gravity



Denver IR-120 Moisture Analyser

The IR-120 is the new premium moisture analyser from Denver Instrument. A first, this analyzer uses the new, revolutionary heat source called the CQR (Coiled Quartz Radiator). It guarantees the highest reproducibility and the fastest results. The IR-120 has a motorized sample chamber cover that substantially reduces the effects of the surrounding environment when applying a sample and starting a measurement. The simple operational concept and wide, already integrated software programs, offer a high level of flexibility.



Performance Specifications for the IR-120
Accuracy of the weighing system	1mg
Reproducibility - Initial sample weight >1g (%) - Initial sample weight >5g (%)	+/-0,10 +/-0,02
Readability	0,01%/0,001%
Display of analysis results	Moisture, dry weight, RATIO, residual weight (g or g/kg)
Weighing capacity	120g
Analysis modes	Fully automatic Semi-automatic g/sec. Semi-automatic %/sec. Time-out 3x999min Time-out + Automatic
Temperature settings adjustable in 1-degree steps	30-210°C
Standby-temperature	40-100°C
Program memory locations	100
Serial port for data output to printer or computer	RS232
Built-in printer	GLP-/GMP-compliant printout
3 Warranty

Denver IR-60 Moisture Analyser

The IR-60 sets new standards in the compact category of moisture analyzers. High sample weighing capacity, easier-than-ever operation, space-saving design and a new, revolutionary heat source make the IR-60 an unbeatable analyser in its class. The crucial benefits of the new CQR (Coiled Quartz Radiator) heat source are faster response times with higher reproducibility along with fast and even distribution of the heat on the surface of a sample.



Performance Specifications for the IR-60
Accuracy of the weighing system	1mg
Reproducibility - Initial sample weight >1g (%) - Initial sample weight >5g (%)	+/-0,20 +/-0,05
Readability	0,01%
Display of analysis results	Moisture, dry weight, RATIO, residual weight (g or g/kg)
Weighing capacity	60g
Analysis modes	Fully automatic Semi-automatic 0-20mg/24sec. Time-out 0-99min
Temperature settings adjustable in 1-degree steps	30-210°C
Standby-temperature	40-100°C
Program memory locations	5
Serial port for data output to printer or computer	RS232
3 Year Warranty

Denver IR-35 Moisture Analyser

As the new Moisture Analyser for all purposes, the IR-35 offers a great performance especially matched to the daily needs in a laboratory. Its easy operational concept provides a large and clearly arranged display - that gives all important information at a glance, as well as an easy menu navigation - that directs the user with the help of easy to understand symbols from tearing the sample pan to the beginning of the analysis in just three steps. Thanks to the fully self-controlled determination of the endpoint, no programming of a shutoff criteria is necessary. The moisture determination is monitored continuously and the analysis is stopped once no further weight loss is detected.



Performance Specifications for the IR-35
Accuracy of the weighing system	1mg
Reproducibility - Initial sample weight >1g (%) - Initial sample weight >5g (%)	+/-0,20 +/-0,05
Readability	0,01%
Display of analysis results	Moisture, dry weight, RATIO, residual weight (g or g/kg)
Weighing capacity	35g
Analysis modes	Fully automatic Timer mode 0,1 - 99min
Temperature settings adjustable in 1-degree steps	40-160°C
Serial port for data output to printer or computer	RS232C
Housing dimensions (WxDxH)	224x366x191mm
3 Years Warranty

Denver Laboratory Electrodes For pH Meters

High-Performance Electrodes, Conductivity Cells and Ion-Selective Electrodes

Ion-Selective Electrodes

Fluoride, Chloride and Silver/Sulfide Electrodes
State-of-the-art, convenient, combination ISEs (with built-in reference electrodes) for Fluoride, Chloride and Silver or Sulfide measurement. Membranes are LaF3single crystal membrane (F-), solid-state Ag2S/AgCI (CI-) or solid-stateAg2S (Ag+/S--) refillable references are single junction (F-) or double junction (CI-and Ag+/S--)with high flow rate plastic sleeve junctions for accurate measurements, durable epoxy body, 12 mm diameter, 110 mm length, BNC connector.

·Fluoride Combination ISE
Cat.No.300739.1
·Chloride Combination ISE
Cat.No.300742.1
·Silver/Sulfide Combination ISE
Cat.No.300762.1

Nitrate,Potassium and Calcium Electrodes
Convenient combination ISEs use solvent-polymer PVC membrane technology. Built-in refill-able reference electrodes are single junction (Ca++) or double junction (NO3-and K+) with high flow rate plastic sleeve junctions, durable epoxy body, 12 mm diameter, 120 mm length, BNC connector.

·Nitrate Combination ISE
Cat.No.300743.1
·Potassium Combination ISE
Cat.No.300744.1
·Calcium Combination ISE
Cat.No.300745.1


Sodium Electrode
Combination ISE uses a sodium selective glass membrane. Build-in liquid-filled reference electrode, glass body, 12 mm diameter, 110 mm length, BNC connector.

·Sodium combination ISE
Cat.No.300741.1

Combination ORP Electrode
Used to measure ORP (Oxidation Reduction Potential, or Redox Potential) in samples such as industrial waters. Convenient combination electrode includes Ag/AgCl reference with ceramic junction, large area platinum discsensing element. BNC connector.

·ORP (Redox) Combination ISE
Cat.No.300746.1

Ammonia Electrode
Combination ISE uses replaceable screw-on porous Teflon membrane module, Epoxy body,12 mm diameter, BNC connector.

·Ammonia Combination ISE
Cat.No.300740.1
·Replacement membranes (4 pack)
Cat.No.301252.1




pH and pH/ATC Electrodes

pH/ATC Plastic-body Combination Electrode

For routine pH measurements, pH range 0 to14, Ag/AgCI reference with free-flow fibre junction, ”3-in-1“ electrode has built-in temperature, integral glass bulb guard, 12 mm diameter, 120 mm length, temperature range –5 °C to 80 °C.

·3M KCI liquid-filled electrode, BNC and 2.5 mm phone plug connectors. Standard electrode for Denver UltraBasic Meter with Deluxe Kit.
Cat.No.300728.1

High Performance pH/ATC Glass-body Electrode

For all pH measurements, including TRIS samples. Glass body, pH 0 to 14 low resistance break resistant toughened glass, super-stable 3M KCI liquid-filled reference cartridge system with non clogging Free-Flow platinum junction, built-in temperature, BNC and 2.5 mm phone plug connectors, temperature range –5°C to 100°C.

·For use with all Denver Meters. Standard electrode for Denver 200 series and with UltraBasic Meter with Deluxe Bio-Kit.
Cat.No.300729.1

High Performance Sleeve-Junction pH Electrode

For routine or difficult pH-measurements, viscous or low ionic strength samples. Polymer body, pH 0 to 14 low resistance glass, liquid-filled 3M KCI reference, adjustable flow rate plastic sleeve junction provides control overflow rate, allowing more accurate measurements. BNC connector, temperature range –5 °C to 100 °C.
·For use with all Denver Meters.
Cat.No.300738.1

pH Glass-body Combination Electrode

For all pH measurements, including TRIS samples. Glass body pH 0 to 14 low resistance break-resistant glass, super-stable 3M KCI refillable reference cartridge system with non-clogging Free-Flow platinum junction. BNC connector, temperature range –5 °C to100 °C.
·For use with all Denver Meters.
Cat.No.300731.1

Micro Glass-body Combination pH Electrodes

For pH measurements in narrow containers, test tubes and labware. pH 0 to 14 low resistance glass, 3M KCI refillable reference system with non clogging platinum junction, BNC connector, body diameter 0.20“ (5 mm).

·For use with all Denver Meters.
Cat.No.300736.1



Flat-Surface Combination pH Electrode

For pH measurements of small volumes or surfaces such as meats, cheese, leather or agar. Glass-body gel-filled sealed reference, pH 2 to 13 low resistance glass, temperature range –5 °C to 50 °C, BNC connector.

·For use with all Denver Meters.
Cat.No.300737.1

Plastic-body Gel-filled pH Electrode

For field or plant measurements, where low maintenance is desired. Polymer body, pH 0 to14 low resistance glass, gel filled reference with fibre junction, built-in bulb protector, BNC connector, temperature range –5 °C to 80 °C.

·For use with all Denver Meters.
Cat.No.300735.1

Automatic Temperature Compensating Probe

For temperature measurements and correction. Fast response stainless steel body, 4.7 mm diameter, 120 mm length.

·With 2.5 mm phone plug connector for Denver Meters.
Cat.No.300733.1

Conductivity Cells for 200 Series Meters

Four band platinum band conductivity cells offer better linearity and improved accuracy, built-in temperature, plastic-body, 12 mm diameter, cell constants from 0.5 to 10 cm-1.Removable outer body for cleaning.

·Conductivity/ATC cell, 0.5 cm-1, Multi-pin connector for Denver 200 Series Meters.
Cat.No.301046.1
·Conductivity/ATC cell, 1 cm-1, Multi-pin connector for Denver 200 Series Meters.
Cat.No.301047.1
·Conductivity/ATC cell, 10 cm-1, Multi-pin connector for Denver 200 Series Meters.
Cat.No.301048.1

Multi Sense Conductivity/pH/ATC Cells For Denver 200 Series Meters

Super combination electrode includes a two-band platinum conductivity cell, combination pH-electrode with gelled reference and an ATC temperature sensor. Plastic body, standard 12 mm diameter and 120 mm length. Cell constant 1.0 cm-1.

·Conductivity/pH/ATC Cell, BNC and multi-pin connectors for Denver 200 Series Meters.
Cat.No.301058.1



Denver DLT Budget Balances

This is the real new alternative for all demands in schools, in the Lab or in the factory, where simple and cheap weighing devices are required.

Despite the very attractive prices the Denver DLT offers very reliable and precise weighing results and easy handling with just 3 buttons in the well-known Denver tradition.
2 Years Warranty.

Model	Readability	Capacity	Pan size
DLT-411	0,1g	410g	135x140mm
DLT-211	0,1g	210g	135x140mm
DLT-4100	1g	4100g	135x140mm
DLT-2100	1g	2100g	135x140mm



Features and Equipment

Large Display

Sturdy housing and compact design

Battery - or AC powered (power supply optional)

Energy Saving Mode

Easy handling

External Calibration

Balances are stackable

9 V battery included

Antitheft locking device

Transportation locking device

5 Weighing Units: g / oz / dwt / lb / ozt



XP Range

features include: -Mains or Rechargeable battery driven -Large, easy-to-read liquid crystal display -Multiple weighing units - grams, ounces, troy ounces, pennyweight, carats, grains and taels -Automatic calibration -Parts counting -Percentage weighing -Stainless-steel weighing pan -Overload protection -Battery-saving sleep mode

Common Specifications: Unit dimensions (LxWxH) 7.6 x 8.4 x 2.6" (193 x 213 x 66mm); Net Weight: 4.2 lbs. (1.9 kg); Electrical Requirements: Rechargeable battery 9V/500mA, AC adaptor included. Please specify voltage when ordering. XP-Series precision balances are ideal for educational, industrial and general laboratory weighing applications - or anywhere that versatility, portability and accuracy are important! Each unit comes complete with a rechargeable battery - perfect for field use, process control or anywhere that power is not readily available. Plus there's a battery-saving sleep mode to ensure the power's there when you need it! Student abuse? Not a problem with the rugged XP-Series. They're built to withstand the rigors of educational use and their simplicity makes weighing instruction a breeze! For the busy lab, multiple weighing modes provide the versatility to switch between weighing applications. The XP-Series features: grams, ounces, troy ounces, pennyweight, carats, grains and taels. XP-Series toploaders are ideal for industrial accounts that rely on parts counting or percentage weighing to control inventory or processes. Priced right, the XP-Series is the answer for organizations working within a limited budget. XP-Series Specifications



T-Series Specifications

T-Series Balance Specifications Available with TR, TL or TC-Series Features Analytical Models
Model	64	104	204	220D
Weighing Range	61g	110g	210g	220g/31g
Readability	0.1mg	0.1mg	0.1mg	0.1mg/0.01mg
Linearity	0.2mg	0.2mg	0.2mg	0.2mg
Repeatability, (s)	0.1mg	0.1mg	0.1mg	0.1mg/0.01mg
Stabilization Time	4 sec	4 sec	4 sec	4 sec
Pan Dimensions	3.5" (9cm)	3.5" (9cm)	3.5" (9cm)	3.5" (9cm)
Toploading Models
Model	203	403	402	602
Weighing Range	210g	410g	410g	610g
Readability	0.001g	0.001g	0.001g	0.001g
Linearity	0.002g	0.003g	0.01g	0.01g
Repeatability, (s)	0.001g	0.001g	0.1mg	0.01g
Stabilization Time	2 sec	2 sec	2 sec	2 sec
Pan Dimensions	4.5" (11cm)	4.5" (11cm)	6.0" (11cm)	6.0" (11cm)
Model	2102	4102	2101	4101	6101
Weighing Range	2100g	4100g	2100g	4100g	6100g
Readability	0.02g	0.01g	0.1g	0.1g	0.1g
Linearity	0.01g	0.02g	0.1g	0.1g	0.1g
Repeatability, (s)	0.01g	0.01g	0.1mg	0.1g	0.1g
Stabilization Time	2 sec	2 sec	2 sec	2 sec	2 sec
Pan Dimensions	8.375x8.375" (21x21cm)	6.0" (15cm)	8.375x8.375" (21x21cm)	8.375x8.375" (21x21cm)	8.375x8.375" (21x21cm)





Model	8101	12001	603D	4102D	8102D
Weighing Range	8100g	12000g	610/110g	4100/410g	8100/810g
Readability	0.1g	0.1g	0.01/0.001g	0.1/0.01g	0.1/0.01g
Linearity	0.2g	0.2g	0.01/0.002g	0.1/0.01g	0.2/0.01g
Repeatability, (s)	0.1g	0.1g	0.01/0.001g	0.1/0.01g	0.1/0.01g
Stabilization Time	2 sec	2 sec	2 sec	2 sec	2 sec
Pan Dimensions	8.375x8.375" (21x21cm)	8.375x8.375" (21x21cm)	4.5"" (11cm)	6.0" (15cm)	8.375x8.375" (21x21cm)



Common Specifications
Electrical Requirements:	15VDC @ 800 mA with AC Adapter, center pin (-)
Controls:	Silicone rubber keypad, Zero, Display ON/OFF, and 3 softkeys
Display:	4.5 x 1.75 inch (12.3 x 4 cm) custom LCD
Interface:	RS-232 Bidirectional
Height above pan (analyticals):	9.5" (24cm)
Net Weight:	8.7 lbs. (3.9 kg) Round Pan 10 lbs. (4.5kg) Square Pan 14.6 lbs. (6.6 kg) Analytical
Shipping Weight:	12.0 lbs. (5.4 kg) Round Pan 13.0 lbs. (5.9 kg) Square Pan 17.8 lbs. (8.0 kg) Analytical

Denver Balances T-Series

Introducing the new T-Series balances from Denver Instrument Company. We've raised the standard at Denver Instrument with the release of the new T-Series balances. These new balances exceed all expectations for accuracy, repeatability and stability--so much so that "new and improved" doesn't begin to cover the enhancements: like all Denver Instrument products, they're amazingly affordable! Standard Features for TR, TL and TC-Series:         Simple, menu-driven operation 16 weigh units Animal weighing Parts counting Automatic calibration RS-232C interface

TL and TC-Series Advanced Features: GLP data storage and output Illuminated display Statistical analysis Fill guide with graphical indicator Check weighing Batch weighing Internal calibration (TC-Series only) Whether you're in the market for a basic toploading balance or a full-featured analytical, look to the new T-Series for the latest advancements in precision weighing technology. From the basic TR-Series to the advanced TL and TC Series, there's a balance for every application and every budget. Plus, they're backed by the most comprehensive warranty in the industry. Simply stated, should any T-Series balance fail to perform to specification within the stated warranty period, it will be replaced or repaired at no charge.

Denver Apex Series

APEX Series Analytical and Toploading Balances New APEX-Series balances from Denver Instrument offer simplicity, accuracy and reliability at incredible prices. Comprehensive features make these instruments ideal for laboratory, industrial and educational environments. Value priced Newest technology Easy operation Multiple weighing modes Parts counting Percent weighing Calibration is a snap RS232 interface Built to last Specifications Analytical Models   Capacity Readability Linearity Pan Size APX-60 60g 0.1mg ±0.2mg 3" dia. (76 mm) APX-100 100g 0.1mg ±0.2mg 3" dia. (76 mm) APX-200 200g 0.1mg ±0.2mg 3" dia. (76 mm) Toploading Models APX-153 150g 0.001g ±0.002g 4.5"dia. (114 mm) APX-203 200g 0.001g ±0.002g 4.5"dia. (114 mm) APX-402 400g 0.01g ±0.02g 4.5"dia. (114 mm) APX-602 600g 0.01g ±0.02g 4.5"dia. (114 mm) APX-1502 1500g 0.01g ±0.02g 4.5"dia. (114 mm) APX-2001 2000g 0.1g ±0.2g 5" x 7" (127 x 178 mm) APX-4001 4000g 0.1g ±0.2g 5" x 7" (127 x 178 mm) APX-6001 6000g 0.1g ±0.2g 5" x 7" (127 x 178 mm) Common Specifications: Dimensions (LxWxH) Analytical: 12.7"x 8.8"x 12.25" (322 x 224 x 311 mm) Dimensions (LxWxH) Toploading: 12.7"x 8.8"x 3.0" (322 x 224 x 76 mm) Net Weight Analytical: 9.9 lbs. (4.5 kg) Net Weight Toploading: 4.8 lbs. (2.2 kg) Power Requirements: 15 VDC@100 mA with AC adapter, center pin (-).



Specifications

Denver Ion-Selective Electrodes Specifications
Ion	Measurement Range	Slope (mV/decade)	Temperature Range	Response Time	Filling Solution
Fluoride	0.02 - Saturated	-57 ± 2	0 to 80C	20 sec	KCl
Chloride	1.8 - 35000	-56 ± 2	0 to 80C	20 sec	KNO3
Silver	0.01 - 108000	57 ± 2	0 to 80C	20 sec	KNO3
Sulfide	0.003 - 32000	-27 ± 2	0 to 80C	20 sec	KNO3
Ammonia	0.01 - 17000	56 ± 3	0 to 50C	60 sec	NH4Cl
Sodium	0.02 - Saturated	56 ± 2	0 to 80C	45 sec	NH4Cl
Nitrate	0.5 - 62000	57 ± 2	0 to 50C	30 sec	(NH4)2SO4
Potassium	0.04 - 39000	56 ± 2	0 to 50C	30 sec	NaCl
Calcium	0.2 - 40000	27 ± 2	0 to 50C	30 sec	KCl

Sartorius Competence CP Precision Balances

The Sartorius Competence Series. Innovative product variety for advanced lab weighing in the real world

The Sartorius Competence Series – CP for short – is the new basic series of balances for professional use in the laboratory. The CP sets completely new standards with its unique overall concept combining innovative design and highly advanced mechatronic technology. Eighteen precision balances – from 1 mg to 34 kg – offer high-value product solutions for laboratory weighing applications at an excellent price/performance ratio.

CP models are standard-equipped with the following performance features:

• Backlit LCD. Height of digits: 16.5 mm
• Glass draft shield with removable side panels and hinged cover on 0.001-g models
• Bidirectional RS-232 data interface
• ISO/GLP-compliant recording and printing capability (in combination with the Sartorius printer, YDP03-0CE or a PC)
• Application programs: % weighing, net-total formulation, dynamic weighing/animal weighing, mass unit conversion by toggling, counting



Model
Readability	Capacity	Pan Size	Calibration	Model
Standard models
0.001 g	420 g	Ø 110 mm	extern	CP423S
0.001 g	320 g	Ø 110 mm	extern	CP323S
0.001 g	150 g	Ø 110 mm	extern	CP153
0.001/0.002/0.005 g	80/160/320 g	Ø 110 mm	extern	CP323P
0.01 g	4200 g	190x204 mm	extern	CP4202S
0.01 g	3200 g	190x204 mm	extern	CP3202S
0.01 g	2200 g	190x204 mm	extern	CP2202S
0.01 g	620 g	Ø 154 mm	extern	CP622
0.01/0.02/0.05 g	800/1600/3200 g	190x204 mm	extern	CP3202P
0.1 g	34000 g	300x400 mm	extern	CP34001S
0.1 g	16000 g	300x400 mm	extern	CP16001S
0.1 g	12000 g	300x400 mm	extern	CP12001S
0.1 g	8200 g	190x204 mm	extern	CP8201
0.1 g	6200 g	190x204 mm	extern	CP6201
0.1 g	4200 g	190x204 mm	extern	CP4201
0.1 g	2200 g	190x204 mm	extern	CP2201
0.1/0.2/0.5 g	8000/16000/34000 g	300x400 mm	extern	CP34001P
1 g	34000 g	300x400 mm	extern	CP34000
Verified models with EC type approval
0.001 g	0.02 - 420 g	Ø 110 mm	intern	CP423S-0CE
0.001 g	0.02 - 320 g	Ø 110 mm	intern	CP323S-0CE
0.001 g	0.02 - 150 g	Ø 110 mm	intern	CP153-0CE
0.001/0.002/0.005 g	0.02 - 320 g	Ø 110 mm	intern	CP323P-0CE
0.01 g	0.5 - 4200 g	190x204 mm	intern	CP4202S-0CE
0.01 g	0.5 - 3200 g	190x204 mm	intern	CP3202S-0CE
0.01 g	0.5 - 2200 g	190x204 mm	intern	CP2202S-0CE
0.01 g	0.5 - 620 g	190x204 mm	intern	CP622-0CE
0.01/0.02/0.05 g	0.5 - 3200 g	190x204 mm	intern	CP3202P-0CE
0.1 g	5 - 34000 g	300x400 mm	intern	CP34001S-0CE
0.1 g	5 - 16000 g	300x400 mm	intern	CP16001S-0CE
0.1 g	5 - 12000 g	300x400 mm	intern	CP12001S-0CE
0.1 g	5 - 8200 g	190x204 mm	intern	CP8201-0CE
0.1 g	5 - 6200 g	190x204 mm	intern	CP6201-0CE
0.1 g	5 - 2200 g	190x204 mm	intern	CP2201-0CE
0.1/0.2/0.5 g	5 - 34000 g	300x400 mm	intern	CP34001P-0CE
1 g	50 - 34000 g	300x400 mm	intern	CP34000-0CE



Accessories
Group	Descripion	Order-Nr.
Analytical draft shield	Analytical draft shield for - CP423S, CP323S, CP323P, CP153 - LE623S, LE323S, LE623P	YDS01CP
Carrying case	Carrying case, for - CP423S, CP323S, CP323P, CP153, CP4202S, CP3202S, CP2202S, CP3202P, CP8201, CP6201, CP4201, CP2201 - LE623S, LE323S, LE623P, LE6202S, LE4202S, LE2202S, LE6202P, LE5201, LE10001	YDB02CP
Data printer	Ink ribbon cartridge, for YDP03-OCE	6906918
Data printer	Paper rolls, for YDP03-OCE; 5 units, each with 50 m	6906937
Data printer	Data printer, suitable for use in legal metrology; with date,time,statistics and transaction counter functions	YDP03-0CE
Draft shield cover	Draft shield cover with opening for - CP423S, CP323S, CP153, CP323P - LE623S. LE623P, LE323S	YDS02CP
Foot switch	Foot switch, for activating the print, tare or F key; function can be selected by menu code; incl. T-connector for series CP, ED, LA, LE and TE	YFS01
Hand switch	Hand switch, for activating the print, tare or F key; function can be selected by menu code; incl. T-connector	YHS02
Hanger for below-balance weighing	Hanger for below-balance weighing, screw thread for attachment to - CP34001S, CP16001S, CP12001S, CP34001P, CP34000 - LE34001S, LE16001S, LE34001P	69EA0040
Interface cable	RS-232C interface cable, for connecting the balance to a PC with a 25-pin COM port; length approx. 1.5 m	7357312
Interface cable	RS-232C interface cable, for connecting the balance to a PC with a 9-pin COM port; length approx. 1.5 m	7357314
Interface cable	RS-232/USB connecting cable (length: approx. 1.8 m); CD with software drivers for installation under Windows 98/ME/2000/XP	YCC01-USBM2
Ionizing blower	Ionizing blower (220V) for electrostatically charged samples	YIB01-0DR
Ionizing blower	Ionizing blower (110V) for electrostatically charged samples	YIB01-0UR
Protective cover	Protective cover for display unit CP34001S, CP16001S, CP12001S, CP34001P, CP34000	6960CP01
Protective cover	Protective cover for models CP423S, CP323S, CP323P, CP153, CP622	6960CP02
Protective cover	Protective cover for models CP4202S, CP3202S, CP2202S, CP3202P, CP8201, CP6201, CP4201, CP2201	6960CP03
Rechargeable battery pack	External rechargeable battery pack for balances with a weighing capacity up to ... - Series CP: 8.2 kg - Series LE: 10.2 kg - Series ED: all models - Series ME: all models - Series SE: all models	YRB05Z
Rechargeable battery pack	External rechargeable battery pack for balances with a weighing capacity up to ... - Series CP: from 12 kg up to 34 kg - Series LA: all models - Series LE: from 16 kg up to 34 kg	YRB06Z
Remote display	Remote display LCD; height of digits; 13 mm; reflective	YRD02Z
Software	SartoConnect, data transfer software, for direct input of weighing data into an application program (e.g., such as Excel) with RS232C standard cable, length: 1 m	YSC01L
Software	SartoConnect, data transfer software, for direct input of weighing data into an application program (e.g., such as Excel) with RS232C standard cable, length: 15 m	YSC01L15
Software	SartoConnect, data transfer software, for direct input of weighing data into an application program (e.g., such as Excel) with RS232C standard cable, length: 5 m	YSC01L5
Standard Operating Procedure (SOP)	Standard Operating Procedure (SOP) in German	YSL01D
Standard Operating Procedure (SOP)	Standard Operating Procedure (SOP) in English	YSL01E
Stat pen	Stat pen, unit to neutralize static electricity on samples (100V to 230V, 50/60Hz)	YSTP01
T-connector	T-connector, for connecting two peripheral devices to the balance	YTC01
Weighing bowls	Weighing bowl: Made of chrome nickel steel; without pouring spout; 1,000 ml capacity for balances with a weighing capacity > 300 g	641211
Weighing bowls	Weighing bowl: Made of chrome nickel steel; without pouring spout; 500 ml capacity	641212

Sartorius Competence CP Balances

The Sartorius Competence Series. An introduction in the world of micro weighing.

The Competence microbalance CP2P is designed for users who do not process a high volume of samples, and only occasionally work with the miniscule sample quantities that must be analyzed with microgram accuracy. This “entry-level” model offers incomparable value for money.



• Monolithic weighing technology – rugged, accurate, reliable – for years
• Built-in motorized calibration weight. Maximum weighing accuracy simply at the press of a key
• Innovative glass draft shield specially designed for microbalances, with smooth-action doors and ideal features for easy, „spotless“ cleaning
• Exceptionally easy-to-read, high contrast display with especially large digits (16.5 mm)
• Specially designed model CP2P-F for weighing filters, featuring a rotatable cover, which enables fast loading of filters up to a diameter of 120mm.



Model
Readability	Capacity	Pan Size	Calibration	Model
Standard models
0.001/0.002/0.005 mg	0.5/1/2 g	Ø 20 mm	intern	CP2P
0.001/0.002/0.005 mg	0.5/1/2 g	Ø 20 oder/or125 mm	intern	CP2P-F



Accessories
Group	Description	Order-Nr.
Balance table / Wall console	Balance table, for precise, reliable weighing operations	YWT01
Balance table / Wall console	Balance table, cast stone with damping device	YWT03
Balance table / Wall console	Wall console	YWT04
Data printer	Ink ribbon cartridge, for YDP03-OCE	6906918
Data printer	Paper rolls, for YDP03-OCE; 5 units, each with 50 m	6906937
Data printer	Data printer, suitable for use in legal metrology; with date, time, statistics and transaction counter functions	YDP03-0CE
Foot switch	Foot switch, for activating the print, tare or F key; function can be selected by menu code; incl. T-connector for series CP, ED, LA, LE and TE	YFS01
Hand switch	Hand switch, for activating the print, tare or F key; function can be selected by menu code; incl. T-connector	YHS02
Interface cable	RS-232C interface cable, for connecting the balance to a PC with a 25-pin COM port; length approx. 1.5 m	7357312
Interface cable	RS-232C interface cable, for connecting the balance to a PC with a 9-pin COM port; length approx. 1.5 m	7357314
Interface cable	RS-232/USB connecting cable (length: approx. 1.8 m); CD with software drivers for installation under Windows 98/ME/2000/XP	YCC01-USBM2
Ionizing blower	Ionizing blower (220V) for electrostatically charged samples	YIB01-0DR
Ionizing blower	Ionizing blower (110V) for electrostatically charged samples	YIB01-0UR
Rechargeable battery pack	External rechargeable battery pack for balances with a weighing capacity up to ... - Series CP: 8.2 kg - Series LE: 10.2 kg - Series ED: all models - Series ME: all models - Series SE: all models	YRB05Z
Remote display	Remote display LCD; height of digits; 13 mm; reflective	YRD02Z
Software	SartoConnect, data transfer software, for direct input of weighing data into an application program (e.g., such as Excel) with RS232C standard cable, length: 1 m	YSC01L
Software	SartoConnect, data transfer software, for direct input of weighing data into an application program (e.g., such as Excel) with RS232C standard cable, length: 15 m	YSC01L15
Software	SartoConnect, data transfer software, for direct input of weighing data into an application program (e.g., such as Excel) with RS232C standard cable, length: 5 m	YSC01L5
Standard Operating Procedure (SOP)	Standard Operating Procedure (SOP) in German	YSL01D
Standard Operating Procedure (SOP)	Standard Operating Procedure (SOP) in English	YSL01E
Stat pen	Stat pen, unit to neutralize static electricity on samples (100V to 230V, 50/60Hz)	YSTP01
T-connector	T-connector, for connecting two peripheral devices to the balance	YTC01



Sartorius Competence CP Balances

The Sartorius Competence Series. Innovative product variety for advanced lab weighing in the real world

The Sartorius Competence Series – CP for short – is the new basic series of balances for professional use in the laboratory. The CP sets completely new standards with its unique overall concept combining innovative design and highly advanced mechatronic technology. Five analytical balances – from 0.01 mg to 320 g – offer high-value product solutions for laboratory weighing applications at an excellent price/performance ratio.

CP models are standard-equipped with the following performance features:

• Backlit LCD (model CP225D without backlighting). Height of digits: 16.5 mm
• All-glass draft shield
• Bidirectional RS-232 data interface
• Built-in, motorised calibration weight
• ISO/GLP-compliant recording and printing capability (in combination with the Sartorius printer, YDP03-0CE or a PC)



Model
Readability	Capacity	Pan Size	Calibration	Model
Standard models
0.01/0.1 mg	80 / 220 g	Ø 80 mm	intern	CP225D
0.1 mg	320 g	Ø 80 mm	intern	CP324S
0.1 mg	220 g	Ø 80 mm	intern	CP224S
0.1 mg	120 g	Ø 80 mm	intern	CP124S
0.1 mg	64 g	Ø 80 mm	intern	CP64
Verified models with EC type approval
0.01/0.1 mg	0.001 - 220 g	Ø 80 mm	intern	CP225D-0CE
0.1 mg	0.01 - 320 g	Ø 80 mm	intern	CP324S-0CE
0.1 mg	0.01 - 220 g	Ø 80 mm	intern	CP224S-0CE
0.1 mg	0.01 - 120 g	Ø 80 mm	intern	CP124S-0CE
0.1 mg	0.01 - 64 g	Ø 80 mm	intern	CP64-0CE



Accessories
Group	Descripion	Order-Nr.
Antistatic weighing pan	Antistatic weighing pan for - CP225D, CP324S, CP124S, CP224S, CP64 - LE225D	YWP01CP
Balance table / Wall console	Balance table, for precise, reliable weighing operations	YWT01
Balance table / Wall console	Balance table, cast stone with damping device	YWT03
Balance table / Wall console	Wall console	YWT04
Carrying case	Carrying case, for - CP225D, CP324S, CP224S, CP124S, CP64 - LE225D, LE324S, LE244S, LE1003P, LE1003S, LE5202S-DS, LE2202S-DS	YDB01CP
Data printer	Ink ribbon cartridge, for YDP03-OCE	6906918
Data printer	Paper rolls, for YDP03-OCE; 5 units, each with 50 m	6906937
Data printer	Data printer, suitable for use in legal metrology; with date, time, statistics and transaction counter functions	YDP03-0CE
Density determination kit	Density determination kit for - CP225D, CP324S, CP224S, CP124S - all ME models (0.1 mg and 0.01 mg readability) and LA models (0.1 mg readability) - LE225D	YDK01
Foot switch	Foot switch, for activating the print, tare or F key; function can be selected by menu code; incl. T-connector for series CP, ED, LA, LE and TE	YFS01
Hand switch	Hand switch, for activating the print, tare or F key; function can be selected by menu code; incl. T-connector	YHS02
Interface cable	RS-232C interface cable, for connecting the balance to a PC with a 25-pin COM port; length approx. 1.5 m	7357312
Interface cable	RS-232C interface cable, for connecting the balance to a PC with a 9-pin COM port; length approx. 1.5 m	7357314
Interface cable	RS-232/USB connecting cable (length: approx. 1.8 m); CD with software drivers for installation under Windows 98/ME/2000/XP	YCC01-USBM2
Ionizing blower	Ionizing blower (220V) for electrostatically charged samples	YIB01-0DR
Ionizing blower	Ionizing blower (110V) for electrostatically charged samples	YIB01-0UR
Protective cover	Protective cover for display unit CP225D, CP324S, CP224S, CP124S, CP64	6960CP04
Rechargeable battery pack	External rechargeable battery pack for balances with a weighing capacity up to ... - Series CP: 8.2 kg - Series LE: 10.2 kg - Series ED: all models - Series ME: all models - Series SE: all models	YRB05Z
Remote display	Remote display LCD; height of digits; 13 mm; reflective	YRD02Z
Software	SartoConnect, data transfer software, for direct input of weighing data into an application program (e.g., such as Excel) with RS232C standard cable, length: 1 m	YSC01L
Software	SartoConnect, data transfer software, for direct input of weighing data into an application program (e.g., such as Excel) with RS232C standard cable, length: 15 m	YSC01L15
Software	SartoConnect, data transfer software, for direct input of weighing data into an application program (e.g., such as Excel) with RS232C standard cable, length: 5 m	YSC01L5
Standard Operating Procedure (SOP)	Standard Operating Procedure (SOP) in German	YSL01D
Standard Operating Procedure (SOP)	Standard Operating Procedure (SOP) in English	YSL01E
Stat pen	Stat pen, unit to neutralize static electricity on samples (100V to 230V, 50/60Hz)	YSTP01
T-connector	T-connector, for connecting two peripheral devices to the balance	YTC01



Apex Precision Balances APX6001 - APX2001

Strong basics for laboratory environments. Three years long-term guarantee.    Model Readability Capacity Pan size Calibration APX-6001 0,1g 6.000g 127x178mm external APX-4001 0,1g 4.000g 127x178mm external APX-2001 0,1g 2.000g 127x178mm external   Features Automatic external Calibration RS232 Interface Power supply   Applications Parts Counting Weighing in % Multiple weigh units     Apex Precision Balances APX-3202 - APX-153     Strong basics for laboratory environments. Three years long-term guarantee.    Model Readability Capacity Pan size Calibration APX-3202 0,01g 3.200g        ø 150mm external APX-1502 0,01g 1.500g        ø 114mm external APX-602 0,01g 600g        ø 114mm external APX-402 0,01g 400g        ø 114mm external APX-323   1mg 320g        ø 114mm external APX-203   1mg 200g        ø 114mm external APX-153   1mg 150g        ø 114mm external   Features Automatic external Calibration RS232 Interface Power supply   Applications Parts Counting Weighing in % Multiple weigh units

Denver Balances Pinnacle Series Specifications

Analytical Models	P-114*	P-214*	P-314*
Capacity	110g	210g	310g
Readability	0.1mg	0.1mg	0.1mg
Repeatability	0.1mg	0.1mg	0.1mg
Linearity	0.2mg	0.2mg	0.3mg
Pan Dimensions	3.1" dia.	3.1" dia.	3.1" dia.
	(79 mm)	(79mm)	(79 mm)
Toploading Models	P-203*	P-403*	P-603D*	P-402*	P-602*	P-2002*
Capacity	200g	400g	100/600g	400g	600g 2000g
Readability	0.001g	0.001g	0.001/0.01g	0.01g	0.01g	0.01g
Repeatability	0.001g	0.001g	0.002/0.01g	0.01g	0.01g	0.01g
Linearity	0.002g	0.002g	0.003/0.02g	0.02g	0.02g	0.02g
Pan Dimensions	4.5" dia.	4.5" dia.	4.5" dia.	4.5" dia.	4.5" dia.	7.0" x 7.0"
	(114mm)	(114mm)	(114mm)	(114mm)	(114 mm)	(178 x 178mm)
Toploading Models	P-4002*	P-4002D*	P-8002D	P-6001*	P-8001
Capacity	4000g	400/4000g	800/8000g	6000g	8000g
Readability	0.01g	0.01/0.1g	0.01/0.1g	0.1g	0.1g
Repeatability	0.01g	0.02/0.1g	0.01/0.1g	0.1g	0.1g
Linearity	0.02g	0.03/0.2g	0.03/0.2g	0.2g	0.2g
Pan Dimensions	7.0" x 7.0"	7.0" x 7.0"	7.0" x 7.0"	7.0" x 7.0"	7.0" x 7.0"
	(178 x 178mm)	(178 x 178mm)	(178 x 178mm)	(178 x 178mm)	(178 x 178mm)



Common Specifications
Dimensions Analyticals (LxWxH):	14.6" x 9.4" x 13.3" (371 x 239 x 338mm)
Dimensions Toploaders (LxWxH):	14.6" x 9.4" x 3.8" (371 x 239 x 97mm)
Weighing Chamber Dimensions:	8.3" x 8.0" x 9.8" (211 x 203 x 249mm)
Net Weight (Analyticals):	15 lbs. (6.80kg)
Net Weight (Toploaders):	10 lbs. (4.54kg)
Operating Temperature:	10o - 30oC (50o- 86o F)
Storage Temperature:	-10o - 30o C (14o - 86o F)
Humidity:	Less than 90% RH
Stabilization Time:	3 seconds
Electrical Requirements:	115V 50/60Hz, other voltages available

* Models also available as PI-Series with internal calibration. Simply press the calibration key and calibration is completed automatically with precision internal weights.





Denver Balances Pinnacle Series

Pinnacle Series balances from Denver Instrument combine the latest advances in weighing technology with a superior, yet simple, user-interface.

Analytical balances with capacities from 110 to 310 grams offer a 9.5" (241mm) high weighing chamber with easy-access top and side sliding doors.

Toploading balances with capacities from 200 grams to 8 kilograms are perfect for a variety of applications. There are three dual range models offering increased versatility.

Pinnacle balances feature large, powerful back-lit displays, automatic calibration, multiple weigh modes, parts counting, animal weighing, built-in statistical functions, programmable environmental settings, RS232 and USB interface ports.

Apex Analytical Balances APX 60 - APX 200

Analytical Balances with king size weighing chamber. Three years long-term guarantee.    Model Readability Capacity Pan size Calibration APX-200 0,1mg 200g          ø 76mm external APX-100 0,1mg 100g          ø 76mm external APX-60 0,1mg 60g          ø 76mm external   Features Automatic external Calibration RS232 Interface Power supply   Applications Parts Counting Weighing in % Multiple weigh units MAXX Series   MAXimum Balance - Minimum Price The MAXX-Series offers high precision up to mg-accuracy and an extensive range of models - all at an unbeatable price. Latest, microprocessor controlled weighing technology guaranties fast and precise results at any time. Also the MAXX-Series includes an extensive range of application programs and easy and comfortable handling, e.g. a back lit display. All these features of the new MAXX-Series, at an unrivalled price.    Model Readability Capacity Pan size MXX-123 0,001g          120g          ø 97mm MXX-212 0,01g          210g          ø 97mm MXX-412 0,01g          410g          142x130mm MXX-612 0,01g          610g          142x130mm MXX-601 0,1g          610g          142x130mm MXX-2001 0,1g          2000g          142x130mm MXX-5001 0,1g          5000g          142x130mm MXX-5 1g          5kg          142x130mm MXX-10 1g          10kg          142x130mm   Features Huge, back lighted display for comfortable readouts Protected foil and large, clearly defined buttons for easy handling Maximum overload protection Stainless steel weighing pan Compact design Simple and logical user guidance Fuly-automatic, external Calibration Calibration weight included in MXX-123, MXX-212, MXX-412, MXX-612 AC-adapter or battery operated (MXX-123 power supply only ) AC-adapter included Bi-directional RS-232 or USB interface as an option for easy data communication 2 Year Warranty   Applications Weighing in 13 different weighing units Toggling between two different weighing units Counting %Weighing Formulation Static Display Determination of specific gravity   Sartorius CP Balances Sartorius Weighing Technology | Laboratory Balances | Competence CP Series   The Sartorius Competence Series – CP for short – is the new basic series of balances for professional use in the laboratory. The CP sets completely new standards with its unique overall concept combining innovative design and highly advanced mechatronic technology. Twenty-three models – from 0.01 mg to 34 kg – offer high-value product solutions for laboratory weighing applications at an excellent price/performance ratio. CP models are standard-equipped with the following performance features: Backlit LCD (model CP225D without backlighting) Height of digits: 16.5 mm Glass draft shield with removable side panels and hinged cover on 0.001-g models All-glass draft shield on models with 0.01-mg/0.1-mg readability Bidirectional RS-232 data interface Built-in, motorised calibration weight(semi-micro/analytical balances) Automatic calibration and adjustment at the press of a key (all precision balances) with external weights Hanger for below-balance weighing (optional for design 5) Overload protection ISO/GLP-compliant recording and printing capability (in combination with the Sartorius printer, YDP03-0CE or a PC) Application programs: % weighing, net-total formulation, dynamic weighing/animal weighing, mass unit conversion by toggling, counting Print mode for current menu settings Electronic filters for adapting the balance to the ambient conditions Levelling feet, level indicator, lug for attaching an anti-theft locking device (for balances with a weighing capacity up to 8.2 kg) Two tare keys (for left- and right-handed persons) Keys with positive click action * Triangular weighing pan shape Ø = diameter of the inner circle; the shaded area is completely available for use in addition   Model Readability Weighing capacity Verification scale interval Pan size Response time Design   (mg) (g) (g) (mm) average (s)   Semi-microbalance CP225D 0.01/0.01/0.1 40/80/220   Ø 80* 12/12/3 4 CP225D-0CE 0.01/0.01/0.1 0.001 - 220 0.001 Ø 80* 12/12/3 4 Analytical balances CP324S 0.1 320   Ø 80* 3 4 CP324S-0CE 0.1 0.01 - 320 0.001 Ø 80* 3 4 CP224S 0.1 220   Ø 80* 2 4 CP224S-0CE 0.1 0.01 - 220 0.001 Ø 80* 2 4 CP124S 0.1 120   Ø 80* 2 4 CP124S-0CE 0.1 0.01 - 120 0.001 Ø 80* 2 4 CP64 0.1 64   Ø 80* 2 4 CP64-0CE 0.1 0.01 - 64 0.001 Ø 80* 2 4               Model Readability Weighing capacity Verification scale interval Pan size Response time Design   (g) (g) (g) (mm) average (s)   Precision balances CP423S 0.001 420   Ø 110* 1,5 3 CP423S-0CE 0.001 0.02 - 420 0.01 Ø 110* 1,5 3 CP323S 0.001 320   Ø 110* 1,5 3 CP323S-0CE 0.001 0.02 - 320 0.01 Ø 110* 1,5 3 CP323P 0.001/0.002/0.005 80/160/320   Ø 110* 1,5 3 CP323P-0CE 0.001/0.002/0.005 0.02 - 320 0.01 Ø 110* 1,5 3 CP153 0.001 150   Ø 110* 1,5 3 CP153-0CE 0.001 0.02 - 150 0.01 Ø 110* 1,5 3 CP4202S 0.01 4.200   190x204 1,5 2 CP4202S-0CE 0.01 0.5 - 4.200 0.1 190x204 1,5 2 CP3202S 0.01 3.200   190x204 1,5 2 CP3202S-0CE 0.01 0.5 - 3.200 0.1 190x204 1,5 2 CP3202P 0.01/0.02/0.05 800/1.600/3.200   190x204 1,5 2 CP3202P-0CE 0.01/0.02/0.05 0.5 - 3.200 0.1 190x204 1,5 2 CP2202S 0.01 2.200   190x204 1,5 2 CP2202S-0CE 0.01 5 - 2.200 0.1 190x204 1,5 2 CP622 0.01 620   Ø 154* 1 1 CP622-0CE 0.01 0.5 - 620 0.1 Ø 154* 1 1 CP8201 0.1 8.200   190x204 1 2 CP8201-0CE 0.1 5 - 8.200 1 190x204 1 2 CP6201 0.1 6.200   190x204 1 2 CP6201-0CE 0.1 5 - 6.200 1 190x204 1 2 CP4201 0.1 4.200   190x204 1 2 CP2201 0.1 2.200   190x204 1 2 CP2201-0CE 0.1 5 - 2.200 0.1 190x204 1 2 CP34001S 0.1 34.000   400x300 2 5 CP34001P 0.1/0.2/0.5 8.000/16.000/34.000   400x300 1,5 5 CP16001S 0.1 16.000   400x300 1,5 5 CP12001S 0.1 12.000   400x300 1,5 5 CP34000 1 34.000   400x300 1,5 5   Accessories Order no. Suitable for Printer YDP03-0CE All models Rechargeable battery pack YRB05Z All models with a capacity <10 kg   YRB06Z All models with a capacity >10 kg Remote display YRD02Z (reflective) All models   YRD13Z (overhead projectors) All models Analytical draft shield chamber YDS01CP CP423S, CP323S, CP153, CP323P Anti-static pan YWP01CP All semi-micro/analytical balances Density kit YDK01 All semi-micro/analytical balances SartoConnect data transfer software program YSC01L All models Additional accessories available on request Sartorius BL Balances Sartorius Weighing Technology | Laboratory Balances | Basiclite (BL) Series   Rugged, easy-to-use balance; ideal as a school balance for the educational market, as a second balance, and for remote use away from an AC power source; solid weighing technology, high-quality craftsmanship and an excellent price/performance ratio are the major features of each Basic Lite. User-friendly: set it up, turn it on, and weigh Easy-to-read, bright and high-contrast display All keys feature positive click action and provide excellent tactile feedback so you are sure that a function has been activated Also battery-operable (9 V commercially available battery) as an alternative to AC power - ideal for use in the field with up to 11 hours of operation (except for models BL150S and BL1500S) Mass unit conversion by toggling between any 2 of 19 selectable weight units at the touch of a key - for example, g and ozt or dwt and ct Built-in application programs for counting, weighing in percent, and net-total formulation Rugged, space-saving housing Stainless steel weighing pan Bidirectional RS-232 data interface available as an option   Readability (g) Capacity (g) Pan size (mm) Model  0.001 150 Ø 100 BL150S  0.01 1,500 174x143 BL1500S  0.01 610 Ø 116 BL610  0.01 310 Ø 116 BL310  0.01 150 Ø 116 BL150  0.1 6,100 174x143 BL6100  0.1 3,100 174x143 BL3100  0.1 1,500 174x143 BL1500  0.1 600 174x143 BL600  1 12,000 174x143 BL12  1 6,000 174x143 BL6  1 3,000 174x143 BL3 A Sampling of the Range of Accessories RS-232C data interface; installation kit YDO01BL Data printer (YDO01BL required) YDP03-0CE or YDP04 Dust cover for models BL150S, BL610, BL310, BL150 YDC02BL Dust cover for models BL1500S, BL6100, BL3100,BL1500, BL600, BL12, BL6, BL3 YDC01BL Carrying case YDB01BL Remote display, LCD; height of digits: 13 mm; reflective (YDO01BL required) YRD12Z Remote display, LCD; height of digits: 13 mm; for overhead projectors (YDO01BL required) YRD13Z Rechargeable battery pack, external (20 or 40 hours of operation, depending on model), including battery charger YRB07Z

Sartorius BL Balances

Sartorius Weighing Technology | Laboratory Balances | Basiclite (BL) Series



Rugged, easy-to-use balance; ideal as a school balance for the educational market, as a second balance, and for remote use away from an AC power source; solid weighing technology, high-quality craftsmanship and an excellent price/performance ratio are the major features of each Basiclite. User-friendly: set it up, turn it on, and weigh Easy-to-read, bright and high-contrast display All keys feature positive click action and provide excellent tactile feedback so you are sure that a function has been activated Also battery-operable (9 V commercially available battery) as an alternative to AC power - ideal for use in the field with up to 11 hours of operation (except for models BL150S and BL1500S) Mass unit conversion by toggling between any 2 of 19 selectable weight units at the touch of a key - for example, g and ozt or dwt and ct Built-in application programs for counting, weighing in percent, and net-total formulation Rugged, space-saving housing Stainless steel weighing pan Bidirectional RS-232 data interface available as an option



Readability (g)	Capacity (g)	Pan size (mm)	Model
0.001	150	Ø 100	BL150S
0.01	1,500	174x143	BL1500S
0.01	610	Ø 116	BL610
0.01	310	Ø 116	BL310
0.01	150	Ø 116	BL150
0.1	6,100	174x143	BL6100
0.1	3,100	174x143	BL3100
0.1	1,500	174x143	BL1500
0.1	600	174x143	BL600
1	12,000	174x143	BL12
1	6,000	174x143	BL6
1	3,000	174x143	BL3

A Sampling of the Range of Accessories

RS-232C data interface; installation kit	YDO01BL
Data printer (YDO01BL required)	YDP03-0CE or YDP04
Dust cover for models BL150S, BL610, BL310, BL150	YDC02BL
Dust cover for models BL1500S, BL6100, BL3100,BL1500, BL600, BL12, BL6, BL3	YDC01BL
Carrying case	YDB01BL
Remote display, LCD; height of digits: 13 mm; reflective (YDO01BL required)	YRD12Z
Remote display, LCD; height of digits: 13 mm; for overhead projectors (YDO01BL required)	YRD13Z
Rechargeable battery pack, external (20 or 40 hoursof operation, depending on model), including battery charger	YRB07Z

Additional accessories available on request.



Sartorius BL1500S BL1500S Rugged, easy-to-use balance; ideal as a school balance for the educational market, as a second balance, and for remote use away from an AC power source; solid weighing technology, high-quality craftsmanship and an excellent price/performance ratio are the major features of each Basiclite.         Weighing capacity 1500 g  Readability 0.01 g  Verification scale interval   Verifiable for legal metrology   Pan size 174x143 mm  Response time 2.5 s  Data interface RS232 optional  Battery-operable yes  Calibration manual - external weight  GLP/GMP Printouts   Built-in programs net total, weighing in percent, counting, mass unit conversion by toggling, weighing in unstable environments (averaging of weights based on your choice of a preset number of individual measurements (5/10/20/50/100)  Miscellaneous   Setting a New Standard Introducing the new T-Series balances from Denver Instrument Company. We've raised the standard at Denver Instrument with the release of the new T-Series balances. These new balances exceed all expectations for accuracy, repeatability and stability--so much so that "new and improved" doesn't begin to cover the enhancements: like all Denver Instrument products, they're amazingly affordable! Standard Features for TR, TL and TC-Series:   Simple, menu-driven operation 16 weigh units Animal weighing Parts counting Automatic calibration RS-232C interface b  TL and TC-Series Advanced Features:   GLP data storage and output Illuminated display Statistical analysis Fill guide with graphical indicator Check weighing Batch weighing Internal calibration (TC-Series only) Whether you're in the market for a basic toploading balance or a full-featured analytical, look to the new T-Series for the latest advancements in precision weighing technology. From the basic TR-Series to the advanced TL and TC Series, there's a balance for every application and every budget. Plus, they're backed by the most comprehensive warranty in the industry. Simply stated, should any T-Series balance fail to perform to specification within the stated warranty period, it will be replaced or repaired at no charge.
