Misonix S4000 Sonicator

New S4000 Ultrasonic Processors Takes You One Step Further

The new Sonicator 4000 is the world's most advanced ultrasonic processor. A variety of new features including digital processing and touch screen control make this the most intuitive and easy to use system available. Output amplitude is controlled from 0-100% giving a greater degree of resolution and the ability to pinpoint the amplitude needed to effectively process your sample.

The Sonicator tracks frequency changes in the converter / tip assembly caused by load and temperature changes and maintains electrical efficiency at all times. This results in more efficient operation and consistent, reproducible results. Self diagnostics and help screens make operation simple and trouble-free.

Specification:

Maximum Power Output - 600 Watts
Input 100 - 240V, 50 - 60Hz
Programmability 10 memories plus sequencing
Programmable Timer 1 second to 72 hours
Adjustable Pulse On/Off 1 second to 24 hours
Dimensions 11" wide x 20" long x 5.5" high

Sonicator S4000 Features

Fully Digital Design
Digital signal processing enables precise control of amplitude and output power. The result is consistent and reproducible sample processing.

Amplitude Control
Output amplitude is controlled from 1-100% giving a greater degree of resolution and the ability to pinpoint the amplitude needed to effectively process your sample.

Expandable Operating System
Software updates and new features can be downloaded to the Sonicator through the USB port located on the back of the unit. Programs can be e-mailed to the end user and uploaded in minutes. This feature ensures the Sonicator 4000 will always be at the forefront ultrasonic processing.

Touch Screen Control
A large, colour LCD touch screen clearly displays all operating parameters and options.

Self Diagnostics
In the event that a problem is detected, the sonicator will prompt the user that an error has occurred. Help screens offer step by step instructions to help solve the problem.

Programmability
Parameters including processing times, pulse on/off and amplitude can be saved to memory and run by the touch of a button.

Amplitude Control
Output amplitude is controlled from 0-100% giving a greater degree of resolution and the ability to pinpoint the amplitude needed to effectively process your sample.

Pulse Mode
Adjustable pulse On and Off times can be programmed from 1 second to 24 hours.

Run Multiple Programs in Sequence
Multiple programs can be run in sequence. For example, the unit can be programmed to sonicate at 50% amplitude for 5 minutes, shut off for 2 minutes and re-start at 25% amplitude for 10 minutes. Up to 6 programs can be run in succession.

Total Energy Output Display
Energy delivered to the probe is displayed in both Watts and Joules.

Auto Tuning
The Sonicator digitally tracks frequency changes in the converter / tip assembly caused by load and temperature changes and maintains electrical efficiency at all times. Manual tuning (common on older systems) is not necessary.

Overload Protection
The unit is equipped with fault detection circuitry to shut down sonication in the event that an error is detected.

Temperature Monitoring
An optional temperature probe is available for those customers who wish to monitor the temperature of their sample. If the temperature limit is reached, sonication shuts down to prevent overheating of the sample.

RoHS Compliant
The new Sonicator is built lead free.
