LTE Lyotrap Ultra 18kg Freeze Dryer
This is the largest freeze dryer in the range, with an 18kg ice capacity. Having the same controls and features as the Lyotrap, the Lyotrap-Ultra is ideal for high product volumes and long running times between defrosts. This model is well suited for multi-user laboratories and pilot-scale applications. Unlike the rest of the Lyotrap range, the Lyotrap-Ultra includes an integral vacuum pump and is floor standing, supplied with castors.
| Model/Specification |
Lyotrap Ultra |
| Catalogue Number |
LF/LYO/04/1 |
| Compressor |
0.5HP |
| Ice Capacity |
18kg |
| Heat Extraction Rate (-40°C) |
350W |
| Minimum Temperature °C |
-55 |
Chamber Dimensions
diaxD (mm) |
350x655 |
Overall Dimensions
HxWxD (mm) |
1180x670x760 |
Option & Accessories
| LF/LYO/01/0 |
Acrylic drying chamber, 240mm internal dia x 300mm high. |
| LF/LYO/02/0 |
Stainless steel 4-shelf unit, 220mm dia. For acrylic chamber. |
| LF/LYO/03/0 |
8-port flask manifold lid, including 8 x 3/4’ quick seal valves. |
| LF/LYO/04/0 |
Cold trap lid with hose for solvent recovery vacuum pump protection. |
| LF/LYO/05/0 |
Drying chamber plain lid, 250mm dia x 20mm thick. |
| LF/LYO/06/0 |
16-port drum manifold. |
| LF/LYO/07/0 |
24-port drum manifold. |
| LF/LYO/08/0 |
6-tray shelf support to fit inside drum manifold. (if LF/LYO/11/0 fitted) or acrylic chamber. |
| LF/LYO/09/0 |
8-port column manifold. |
| LF/LYO/10/0 |
24-port column manifold. |
| LF/LYO/11/0 |
Temperature-controlled heater mat arrangement (6 mats). |
| LF/LYO/20/0 |
Stoppering shelf arrangement. |
| LF/LYO/30/0 |
48-port ampoule manifold. |
| LF/LYO/31/0 |
Acrylic lid with fitting and clamp to accept ampoule manifold. |
| LF/LYO/32/0 |
Split manifold plus clamps to allow 2 x LF/LYO/30/0 to be fitted. |
| LF/LYO/45/0 |
Pre-freeze bath (-40°C). |
| LF/LYO/50/0 |
1m vacuum hose and clamp to fit Lyotrap, plus KF25 hose for vacuum pump. |
| LF/LYO/51/0 |
2-off ‘L’ section rubber gaskets for drying chamber. |
| FP/PMP/01/0 |
VRC100 vacuum pump plus oil mist filter. |
LTE Lyotrap Plus 4kg Freeze Dryer
This unique bench-top freeze dryer has all the features of the Lyotrap and also incorporates a built-in temperature controllable work chamber complete with three shelves. Four floating temperature probes allow the load temperatures to be monitored, and as an option, the unit can be monitored and controlled via a remote PC. The Lyotrap-Plus has a 4kg ice capacity.
| Model/Specification |
Lyotrap Plus |
| Catalogue Number |
LF/LYO/03/1 |
| Compressor |
0.66HP |
| Ice Capacity |
4kg |
| Heat Extraction Rate (-40°C) |
220W |
| Minimum Temperature °C |
-55 |
Chamber Dimensions
diaxD (mm) |
200x222 |
Overall Dimensions
HxWxD (mm) |
580x920x500 |
Option & Accessories
| LF/LYO/01/0 |
Acrylic drying chamber, 240mm internal dia x 300mm high. |
| LF/LYO/02/0 |
Stainless steel 4-shelf unit, 220mm dia. For acrylic chamber. |
| LF/LYO/03/0 |
8-port flask manifold lid, including 8 x 3/4’ quick seal valves. |
| LF/LYO/04/0 |
Cold trap lid with hose for solvent recovery vacuum pump protection. |
| LF/LYO/05/0 |
Drying chamber plain lid, 250mm dia x 20mm thick. |
| LF/LYO/06/0 |
16-port drum manifold. |
| LF/LYO/07/0 |
24-port drum manifold. |
| LF/LYO/08/0 |
6-tray shelf support to fit inside drum manifold. (if LF/LYO/11/0 fitted) or acrylic chamber. |
| LF/LYO/09/0 |
8-port column manifold. |
| LF/LYO/10/0 |
24-port column manifold. |
| LF/LYO/11/0 |
Temperature-controlled heater mat arrangement (6 mats). |
| LF/LYO/20/0 |
Stoppering shelf arrangement. |
| LF/LYO/30/0 |
48-port ampoule manifold. |
| LF/LYO/31/0 |
Acrylic lid with fitting and clamp to accept ampoule manifold. |
| LF/LYO/32/0 |
Split manifold plus clamps to allow 2 x LF/LYO/30/0 to be fitted. |
| LF/LYO/45/0 |
Pre-freeze bath (-40°C). |
| LF/LYO/50/0 |
1m vacuum hose and clamp to fit Lyotrap, plus KF25 hose for vacuum pump. |
| LF/LYO/51/0 |
2-off ‘L’ section rubber gaskets for drying chamber. |
| FP/PMP/01/0 |
VRC100 vacuum pump plus oil mist filter. |
LTE Lyotrap 5kg Freeze Dryers
This simple to use, microprocessor-controlled bench-top model is packed with useful features. With a 5kg ice capacity, the Lyotrap incorporates an electric defrost facility, displays temperature and vacuum parameters digitally and incorporates a safety system which prevents the vacuum pump being activated until the temperature has reached -30°C.
The Lyotrap is available in 2 condenser temperatures: -55°C and -80°C - the specification of the -80°C condenser Lyotrap (LF/LYO/11/1) is identical to the
-55°C version (LF/LYO/01/1 with the exception of the Minimum Temperature
| Model/Specification |
Lyotrap |
Lyotrap |
| Catalogue Number |
LF/LYO/01/1 |
LF/LYO/11/1 |
| Compressor |
0.66HOP |
0.66HOP |
| Ice Capacity |
5kg |
5kg |
| Heat Extraction Rate (-40°C) |
170W |
170W |
| Minimum Temperature °C |
-55 |
-80 |
Chamber Dimensions
diaxD (mm) |
175x300 |
175x300 |
Overall Dimensions
HxWxD (mm) |
470x650x535 |
470x650x535 |
Option & Accessories
| LF/LYO/01/0 |
Acrylic drying chamber, 240mm internal dia x 300mm high. |
| LF/LYO/02/0 |
Stainless steel 4-shelf unit, 220mm dia. For acrylic chamber. |
| LF/LYO/03/0 |
8-port flask manifold lid, including 8 x 3/4’ quick seal valves. |
| LF/LYO/04/0 |
Cold trap lid with hose for solvent recovery vacuum pump protection. |
| LF/LYO/05/0 |
Drying chamber plain lid, 250mm dia x 20mm thick. |
| LF/LYO/06/0 |
16-port drum manifold. |
| LF/LYO/07/0 |
24-port drum manifold. |
| LF/LYO/08/0 |
6-tray shelf support to fit inside drum manifold. (if LF/LYO/11/0 fitted) or acrylic chamber. |
| LF/LYO/09/0 |
8-port column manifold. |
| LF/LYO/10/0 |
24-port column manifold. |
| LF/LYO/11/0 |
Temperature-controlled heater mat arrangement (6 mats). |
| LF/LYO/20/0 |
Stoppering shelf arrangement. |
| LF/LYO/30/0 |
48-port ampoule manifold. |
| LF/LYO/31/0 |
Acrylic lid with fitting and clamp to accept ampoule manifold. |
| LF/LYO/32/0 |
Split manifold plus clamps to allow 2 x LF/LYO/30/0 to be fitted. |
| LF/LYO/45/0 |
Pre-freeze bath (-40°C). |
| LF/LYO/50/0 |
1m vacuum hose and clamp to fit Lyotrap, plus KF25 hose for vacuum pump. |
| LF/LYO/51/0 |
2-off ‘L’ section rubber gaskets for drying chamber. |
| FP/PMP/01/0 |
VRC100 vacuum pump plus oil mist filter.
|
Freeze Dryers - LTE
|
Mini Lyotrap
This is smallest bench top freeze dryer manufactured by LTE. Having an ice capacity of 3kg, it also represents excellent value. Taking up minimal bench space, the Mini-Lyotrap is ideal for all common freeze drying applications and is also useful as a cold trap for single or multiple units. |
|
Lyotrap
This simple to use, microprocessor-controlled bench-top model is packed with useful features. With a 5kg ice capacity, the Lyotrap incorporates an electric defrost facility, displays temperature and vacuum parameters digitally and incorporates a safety system which prevents the vacuum pump being activated until the temperature has reached -30°C.
The Lyotrap is now available in 2 condenser temperatures: -55°C and -80°C. |
|
Lyotrap Plus
This unique bench-top freeze dryer has all the features of the Lyotrap and also incorporates a built-in temperature controllable work chamber complete with three shelves. Four floating temperature probes allow the load temperatures to be monitored, and as an option, the unit can be monitored and controlled via a remote PC. The Lyotrap-Plus has a 4kg ice capacity. |
|
Lyotrap Ultra
This is the largest freeze dryer in the range, with an 18kg ice capacity. Having the same controls and features as the Lyotrap, the Lyotrap-Ultra is ideal for high product volumes and long running times between defrosts. This model is well suited for multi-user laboratories and pilot-scale applications. Unlike the rest of the Lyotrap range, the Lyotrap-Ultra includes an integral vacuum pump and is floor standing, supplied with castors. |
|
Technical Information
| Model/Specification |
Mini Lyotrap |
Lyotrap |
Lyotrap |
Lyotrap Plus |
Lyotrap Ultra |
| Catalogue Number |
LF/LYO/02/1
|
LF/LYO/01/1 |
LF/LYO/11/1 |
LF/LYO/03/1 |
LF/LYO/04/1 |
| Compressor |
0.5HP
|
0.66HOP |
0.66HOP |
0.66HP |
0.5HP |
| Ice Capacity |
3kg |
5kg |
5kg |
4kg |
18kg |
| Heat Extraction Rate (-40°C) |
80W |
170W |
170W |
220W |
350W |
| Minimum Temperature °C |
-55 |
-55 |
-80 |
-55 |
-55 |
Chamber Dimensions
diaxD (mm) |
175x130 |
175x300 |
175x300 |
200x222 |
350x655 |
Overall Dimensions
HxWxD (mm) |
450x500x400 |
470x650x535 |
470x650x535 |
580x920x500 |
1180x670x760
|
|
